Carrier 40MBQB09D-3 Service Manual

3
QEB
SYSTEM TYPE
Q =HEATPUMP
VOLTAGE
E = 208---230/I/60
INDOOR UNIT
619 P A009
619 = FAN COIL UNIT
P=HIGHWALL
R = CASSETTE, DUCTED, FLOOR CONSOLE
A = ALL MODELS
INDOOR FAN COIL TYPE
B= High Wall
C = Cassette
D=Ducted
F = Floor Console
NOMINAL CAPACITY
009 --- 3/4TON
012 --- 1TON
018 --- 1--- 1/2TONS
024 --- 2TONS
B
M
M=ALL
B=ALL
QER
SYSTEM TYPE
Q =HEATPUMP
VOLTAGE
E = 208---230/I/60
OUTDOOR UNIT
538 T A018
538 = Ai r --- C o o l e d C o n d e n s e r
T =MODEL
A = ALL MODELS
UNIT TYPE
R = OUTDOOR UNIT
NOMINAL CAPACITY
018 --- 11/2TONS
027 --- 21/4TONS
036 --- 3 T O N S
048 --- 4 T O N S
C
MAXIMUM NUMBER OF FAN COIL UNITS THAT
CAN BE CONNECTED TO THE OUTDOOR UNIT
C=1:2
D=1:3
F=1:4OR1:5
M
M =ALL
Use of the AHRI Certified
TM Mark indicates a
manufacturer’s
participation in the
program For verification
of certification for individual
products, go to
www.ahridirectory.org.
