68
Compressor Check
Measure the resistance value of each winding by using the tester.
Position Resistance Value
Blue - Red 0.95 (20℃/68℉) 0.55 (20℃/68℉) 0.53 (20℃/68℉) 0.44 (20℃/68℉)
IPM continuity check
