Carrier 42CA - Page 20

20
Fig. 16 — 42VB Vertical Cabinet Unit with Electric Heater Dimensions
2-1/2
(64)
a42-4384
*Unit weights are based on dry coils and minimum rows. Weights exclude packaging, valves, and other components.
UNIT
SIZE
DIMENSIONS (in.) QTY/UNIT
UNIT WEIGHT*
(lb)
ABCDEBlowerMotor
02 41 22 23 17
1
/
4
3
1
/
8
1163
03 41 22 23 17
1
/
4
3
1
/
8
1168
04 51 32 33 26 3
3
/
4
2182
06 61 42 43 39 2
1
/
4
2199
08 63 44 45 39 3
1
/
4
2 1 101
10 77 58 59 52
1
/
8
3
5
/
8
4 2 133
12 85 66 67 61 3
1
/
4
4 2 154
NOTES:
1. Right hand unit shown; left hand unit opposite.
2. Dimensions shown in inches (mm). All dimensions are
±
1
/
4
inches.
