Carrier 42HQE009 User Manual

REMOTE CONTROLS AND THEIR FUNCTIONS
TEMP
TEMP
CLOCK
CLOCK
SPEED
SPEED
MODE
MODE
ON
OFF
FAN
SPEED
FAN
SPEED
ON
OFF
TEMP.
TEMP
Mode select button
ON/OFF button
Temperature button
Fan speed button
C
C
Each time you push
the button, a mode is
selected in a sequence
that goes from AUTO,
COOL, DRY, HEAT
(cooling only type with-
out), FAN ONLY and
back to AUTO.
Push the button to start
operation, push the
button again to stop
operation.
The set temperature
is increased to 30 C
The set temperature
is decreased to 17 C
:
:
This button is used
for selecting fan
speed. Each time you
push the button, a fan
speed is selected in
a sequence that goes
from AUTO, LOW,
MED, HIGH, and back
to AUTO.
Slide the cover
5
42HQE009/012
R-407C
