External Static Pressure Versus Air Flow Data (Cont.)
External Static Pressure versus Actual Wet Air Flow (Cont.)
42QDMT24
ESP
in.wg
0 0.04 0.08 0.12 0.16 0.20 0.24
Pa 0 10 20 30 40 50 60
Air Flow
cfm cfm cfm cfm cfm cfm cfm
m
3
/h m
3
/h m
3
/h m
3
/h m
3
/h m
3
/h m
3
/h
High Speed
755 713 683 651 614 580 545
1280 1208 1158 1103 1041 983 924
Medium Speed
675 633 603 571 534 500 465
1144 1073 1022 968 905 847 788
Low Speed
430 379 335 288 236 188 141
729 642 568 488 400 319 239
42QDMT30
ESP
in.wg
0 0.04 0.08 0.12 0.16 0.20 0.24 0.28 0.32
Pa 0 10 20 30 40 50 60 70 80
Air Flow
cfm cfm cfm cfm cfm cfm cfm cfm cfm
m
3
/h m
3
/h m
3
/h m
3
/h m
3
/h m
3
/h m
3
/h m
3
/h m
3
/h
High Speed
1080 1036 1005 976 947 915 883 851 819
1831 1756 1703 1654 1605 1551 1497 1442 1388
Medium Speed
910 880 850 820 790 760 730 700 670
1542 1492 1441 1390 1339 1288 1237 1186 1136
Low Speed
645 596 562 525 495 453 411 369 327
1093 1010 952 890 839 768 697 625 554
