CONTROLS SET POINT AND CONFIGURATION LOG
MODEL NUMBER: Software Version
SERIAL NUMBER: MBB CESR131343--
DATE: RCB CESR131249--
TECHNICIAN: ECB CESR131249--
NAVI CESR131227--
SCB CESR131226--
CEM CESR131174--
MARQ CESR131171--
ITEM EXPANSION RANGE DEFAULT ENTRY
UNIT UNIT CONFIGURATION
→ C.TYP Machine Control Type 1 - 6 (multi-text strings) 4
→ CV.FN Fan Mode (0=Auto, 1=Cont) 0 - 1 (multi-text strings) 1
→ RM.CF Remote Switch Config 0 - 3 (multi-text strings) 0
→ CEM CEM Module Installed Yes/No No
→ TCS.C Temp.Cmp.Strt.Cool Factr 0 - 60 min 0
→ TCS.H Temp.Cmp.Strt.Heat Factr 0 - 60 min 0
→ SFS.S Fan Fail Shuts Down Unit Yes/No No
→ SFS.M Fan Stat Monitoring Type 0 - 2 (multi-text strings) 0
→ VAV.S VAV Unocc.Fan Retry Time 0 - 720 min 50
→ SIZE Unit Size (20-60) 20 - 60 20
→ DP.XR Disch.Press. Transducers Yes/No No
→ SP.XR Suct. Pres. Trans. Type 0 -1 (multi-text strings) 0
→ MAT.S MAT Calc Config 0 - 2 (multi-text strings) 1
→ MAT.R Reset MAT Table Entries? Yes/No No
→ ALTI Altitude……..in feet: 0 - 60000 0
→ DLAY Startup Delay Time 0 - 900 sec 0
→ STAT TSTAT_Both Heat and Cool Yes/No No
→ SENS INPUT SENSOR CONFIG
→ SENS → SPT.S Space Temp Sensor Enable/Disable Disable
→ SENS → SP.O.S Space Temp Offset Sensor Enable/Disable Disable
→ SENS → SP.O.R Space Temp Offset Range 1 - 10 5
→ SENS → RRH.S Return Air RH Sensor Enable/Disable Disable
→ SENS → FLT.S Filter Stat.Sw.Enabled ? Enable/Disable Disable
COOL COOLING CONFIGURATION
→ Z.GN Capacity Threshold Adjst –10 → 10 1
→ MC.LO Compressor Lockout Temp –20 → 40 dF 40
→ C.FOD Fan-Off Delay, Mech Cool 0 → 600 sec 60
→ MLV Min. Load Valve? (HGBP) Yes/No No
→ M.M. Motor Master Control Yes/No No
→ HPSP Head Pressure Setpoint 80 - 150 dF 113
→ A1.EN Enable Compressor A1 Enable/Disable Enable
→ A2.EN Enable Compressor A2 Enable/Disable Enable
→ B1.EN Enable Compressor B1 Enable/Disable Enable
→ B2.EN Enable Compressor B2 Enable/Disable Enable
→ CS.A1 CSB A1 Feedback Alarm Enable/Disable Enable
→ CS.A2 CSB A2 Feedback Alarm Enable/Disable Enable
→ CS.B1 CSB B1 Feedback Alarm Enable/Disable Enable
→ CS.B2 CSB B2 Feedback Alarm Enable/Disable Enable
→ REV.R Rev Rotation Verified ? Yes/No No
→ H.SST Hi SST Alert DelayTime 5 - 30 min 10
EDT.R EVAP.DISCHRGE TEMP RESET
→ RS.CF EDT Reset Configuration 0 - 3 (multi-text strings) 0
→ RTIO Reset Ratio 0 - 10 2
→ LIMT Reset Limit 0 - 20 ^F 10
→ RES.S EDT 4-20 ma Reset Input Enable/Disable Disable
