Carrier 50TC-D25 - Typical Smoke Detector System Wiring

31
RETURN AIR SENSOR
(Operating Position Shown)
SCREWS (2)
SAMPLE TUBE
CONTROLLER
MODULE
C12050
Fig. 38 − Return Air Sampling Tube Location in Unit with Economizer
B
D
F
E
A
C
48TM502525 D
C12559
Fig. 39 − Typical Smoke Detector System Wiring
