Page #23 background image
22
HI-WALL split air conditioner
Pos.
Description Part No.
009N
Front panel
10312121229 1
Air filter
10309121202 2
Screw cap
10309121203 3
Panel frame
10309121204 1
Air cleaner
10109121226 1
Air cleaner holder
10109121225 1
Window for receiver
10309121207 1
LED indicator
10309121208 1
Horizontal louver
10309121209 1
Vertical louver
10309121210 1
Air out frame
10309121211 1
Louver holder
10309121212 1
Louver rocker
10309121213 1
Rocker gasket
10309121214 1
Louver motor
10121121218 1
Drain hose
10109121215 1
Evaporator temp sensor
10109121242 1
Left holder for evaporator
10309121217 1
Evaporating coil
10409121201 1
Waterproof board
10718121002 1
Bearing holder
10309121220 1
Blower assembly
10309121221 1
Chassis
10309121222 1
Back cover for chassis
10309121223 1
Installation Plate
10909121009 1
Connecting pipe clamp
10309121225 1
Fan motor
10309121226 1
Motor cover
10309121227 1
E-part box cover
10309121228 1
Indicator holder
10309121229 1
Display board ass’y
10309121240 1
Display board enclosure
10309121231 1
Main control board
10409121001 1
Transformer
10718121006 1
Control box
10718121007 1
Wire clamp
10112121234 1
Wire joint, 5p
10309121242 1
Infrared remote control
10109121207 1
Holder, Remote Controller
10109121208 1
Indoor temp sensor
10109121243 1
Copper nut
TLM-B02 10909121013 1
Copper nut
TLM-A01 10909121012 1
Electric control ass'y
10409121003 1
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
Models
42HQE
Notes
42HQE009N
(
product.
2005)
