Carrier ALLEGRO 42HQE009N User Manual

24
Outdoor unit
Pos. Description Part No. 009
Clamp for front net 10112121801 6
Front net 10109121801 1
Front clapboard 13012111801 1
Propeller fan 10112121803 1
Fan Motor 10112121804 1
Holder for fan motor 50312121801 1
Chassis 10209121807 1
Compressor 10718121817 1
Installation plate for valves 10118113805 1
Gas pipe valve 10409121806 1
4-way valve 10409121808 1
Liquid pipe valve 50118121802 1
Fan motor capacitor 10112121815 1
Installation board for E-parts 15009111801 1
Compressor capacitor 11812113811 1
Capacitor Clamp 10109121822 1
Wire terminal 10109121823 1
Left supporter 13012111803 1
Separating board 10116113813 1
Condenser coil 51609121801 1
Water collector 10118121832 1
Right clapboard 13012111808 1
Big Handle 10112121808 1
Cover 13012111805 1
Small Handle 10830121811 1
Rear net 13012111806 1
Supporter for motor holder 13012111807 1
Copper nut TLM-B02 10909121013 1
Copper nut TLM-A01 10909121012 1
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
Models
38YE Notes
38YE009
( product. 2005)

Carrier ALLEGRO 42HQE009N Specifications

General

Brand	Carrier
Model	ALLEGRO 42HQE009N
Category	Air Conditioner
Language	English
