Carrier ALLEGRO 42HQE009N User Manual

26
HI-WALL split air conditioner
Pos. Descrizione / Description Part No. 012N
Front Panel 10312121228 1
Air Filter 10312121202 2
Screw cap 10312121203 3
Panel frame 10912121002 1
Air cleaner 10109121226 1
Air cleaner holder 10109121225 1
Window for receiver 10412121201 1
Display Panel 10912121003 1
Horizontal louver 10312121205 1
Vertical louver 10312121206 1
Louver motor 10312121207 1
Air out frame 10912121004 1
Louver holder 10312121219 1
Louver rocker 10312121218 2
Rocker gasket 10309121214 2
Drain hose 10112121213 1
Left holder for evaporator 10312121209 1
Evaporator 10412121204 1
Waterproof board 10718121002 1
Bearing holder 10309121220 1
Cross flow fan, assy 10312121213 1
Chassis 10312121214 1
Installation Plate 10312121215 1
Connecting pipe clamp 10309121225 1
Fan motor 10312121216 1
Motor cover 15012113006 1
Remote Controller 10109121207 1
Holder, Remote Controller 10109121208 1
Wire joint, 5p 10109121244 1
Wire clamp 10309121235 1
Display board 10412121001 1
Main control board 10412121002 1
E-Parts Box 10312121223 1
Transformer 10718121006 1
E-part box cover 10312121224 1
Indoor temp sensor 10109121243 1
Evaporator temp sensor 10109121242 1
Connection pipe for drainage 11609121003 1
Sealing ring 31009321021 1
Copper nut TLM-A01 10909121012 1
Copper nut TLM-C03 10912121019 1
Electric control ass'y 10118111005 1
