Carrier ALLEGRO 42HQE009N User Manual

30
HI-WALL split air conditioner
Pos. Description Part No. 018N
Front Panel 10321111047 1
Air filter 10318121202 2
Air cleaner 10109121226 1
Air cleaner holder 10109121225 1
Panel frame 10318121203 1
Display cover 10418111001 1
Evaporator temp sensor 13107121002 1
Clip temperature sensor 10321111036 1
Horizontal louver up 10321111039 1
Horizontal louver down 10321111040 1
Louver motor 10316121202 2
Air outlet frame 10318121208 1
Louver motor cover 10321111045 1
Left holder for evaporator 10318121210 1
Evaporator 10418121201 1
Bearing holder 10318121212 1
Cross flow fan, assy 10318121213 1
Cover left 10318121214 1
Chassis 10318121215 1
Installation Plate 10318121216 1
Connecting pipe clamp 10318121217 1
Relay holder 10318121218 1
Cover right 10318121219 1
Relay proection box 10318121220 1
Fan motor 10318121221 1
Fan motor cover 10318121222 1
Drain hose 10318121223 1
Bush 10318121224 2
louver 10318121225 12
Connect louvers 10318121226 2
Louvers holder 10318121227 1
E-part box cover 10318121228 1
Transformer 10109121204 1
E-Parts Box 11318113002 1
Main control board 10321111041 1
Display board assy 10316121205 1
Cover, indicator light 10318121233 1
Wire clip 10321111042 1
Terminal block 10321111043 1
Wire clamp 10112121234 1
Electric control assembly 10318121209 1
Holder, Remote Controller 10109121208 1
Remote Controller 10109121207 1
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
Models
42HQE Notes
42HQE018N
( product. 2005)
