DETAILED COOLING CAPACITIES
{{
EVAPORATOR
AIR
CONDENSER ENTERING AIR TEMPERATURES deg F
75 85 95 105 115 125
CFM EWB
Capacity
MBtuh†
Total
System
KW**
Capacity
MBtuh†
Total
System
KW**
Capacity
MBtuh†
Total
System
KW**
Capacity
MBtuh†
Total
System
KW**
Capacity
MBtuh†
Total
System
KW**
Capacity
MBtuh†
Total
System
KW**
Total
Sens
‡
Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
24ACA318A30 Outdoor Section With CAP**1814A** Indoor Section
525
72 20.46 10.76 1.21 19.55 10.41 1.36 18.59 10.05 1.53 17.62 9.69 1.71 16.57 9.30 1.91 15.40 8.88 2.13
67 18.79 13.26 1.22 17.95 12.90 1.37 17.05 12.52 1.53 16.12 12.14 1.72 15.13 11.74 1.92 14.03 11.30 2.13
62 17.27 15.73 1.22 16.49 15.36 1.37 15.68 14.97 1.54 14.83 14.55 1.72 14.00 14.00 1.92 13.15 13.15 2.13
57 16.78 16.78 1.23 16.15 16.15 1.37 15.48 15.48 1.54 14.77 14.77 1.72 14.00 14.00 1.92 13.15 13.15 2.13
600
72 20.79 11.28 1.24 19.83 10.92 1.39 18.83 10.55 1.56 17.83 10.19 1.74 16.76 9.80 1.94 15.55 9.37 2.16
67 19.11 14.10 1.25 18.23 13.73 1.40 17.30 13.36 1.56 16.35 12.97 1.74 15.33 12.57 1.94 14.20 12.12 2.16
62 17.66 16.88 1.25 16.87 16.49 1.40 16.06 16.06 1.56 15.32 15.32 1.75 14.51 14.51 1.94 13.61 13.61 2.16
57 17.46 17.46 1.25 16.79 16.79 1.40 16.07 16.07 1.56 15.32 15.32 1.75 14.51 14.51 1.94 13.61 13.61 2.16
675
72 21.03 11.77 1.27 20.02 11.40 1.42 18.99 11.03 1.58 17.97 10.67 1.77 16.88 10.28 1.97 15.65 9.85 2.18
67 19.33 14.90 1.27 18.43 14.54 1.42 17.48 14.15 1.59 16.51 13.77 1.77 15.48 13.35 1.97 14.33 12.89 2.19
62 18.01 17.91 1.28 17.30 17.30 1.43 16.54 16.54 1.59 15.76 15.76 1.77 14.92 14.92 1.97 13.97 13.97 2.19
57 18.01 18.01 1.28 17.30 17.30 1.43 16.55 16.55 1.59 15.76 15.76 1.77 14.92 14.92 1.97 13.97 13.97 2.19
Multipliers for Determining the Performance With Other Indoor Sections
Cooling Indoor
Model
Capacity Power Furnace Model
*CAP**1814A** 1.00 1.00
CAP**2414A** 1.01 1.01
CAP**2417A** 1.01 1.01
CNPF*2418A** 1.00 1.00
CNPH*2417A** 1.00 1.00
CNPV*1814A** 0.99 0.99
CNPV*2414A** 1.00 1.00
CNPV*2417A** 1.00 1.00
CSPH*2412A* * 0.97 0.97
FE4ANF002 1.02 0.93
FF1ENP018 0.99 0.99
FF1ENP024 1.01 1.01
FV4BNF002 1.02 0.93
FX4CNF018 1.01 0.95
FX4CNF024 1.02 0.96
FY4ANF018 0.99 0.99
FY4ANF024 1.00 1.00
Cooling Indoor
Model
Capacity Power Furnace Model
CAP**1814A** 0.98 0.92 58CV(A,X)070---12
CAP**2414A** 1.00 0.94 58CV(A,X)070---12
CNPH*2417A** 0.99 0.93 58CV(A,X)070---12
CNPV*1814A** 0.98 0.92 58CV(A,X)070---12
CNPV*2414A** 0.99 0.93 58CV(A,X)070---12
CSPH*2412A* * 0.95 0.89 58CV(A,X)070---12
CAP**2417A** 1.01 0.95 58CV(A,X)090---16
CNPH*2417A** 0.99 0.93 58CV(A,X)090---16
CNPV*2417A** 0.99 0.93 58CV(A,X)090---16
CSPH*2412A* * 0.95 0.90 58CV(A,X)090---16
CNPH*2417A** 0.99 0.93 58MVB040---14
CSPH*2412A* * 0.95 0.90 58MVB040---14
CAP**2417A** 1.00 0.94 58MVB060---14
CNPH*2417A** 0.99 0.93 58MVB060---14
CNPV*2417A** 0.99 0.93 58MVB060---14
CSPH*2412A* * 0.95 0.90 58MVB060---14
CNPH*2417A** 0.99 0.93 58MVB080---14
CSPH*2412A* * 0.95 0.90 58MVB080---14
See notes on pg. 21
24ACA3
