sor when outdoor-air temperature is too cold. Demand control
ventilation is supported.
This EconoMi$er X system can be used with 1 or 2 speed
indoor fan motor units. (All other speed settings listed are for
future use.)
The EconoMi$er X system utilizes gear-drive technology
with a direct-mount spring return actuator that will close
upon loss of power. The EconoMi$er X system comes stan-
dard with fault detection and diagnostics (FDD), an outdoor
air temperature sensor, and mixed air temperature sensor (al-
so called supply air temperature sensor). Outdoor enthalpy,
indoor (return) dry bulb or enthalpy, and CO
2
sensors are
available for field installation.
Standard integrated barometric relief dampers provide nat-
ural building pressurization control. An optional power ex-
haust system is available for applications requiring even
greater exhaust capabilities. The power exhaust set point is
adjustable at the EconoMi$er X controller.
See Tables 1-3 for package usage. See Table 4 for package
contents. See Table 5 for sensor usage.
* Shipped in hardware kit for field installation.
HW = Honeywell
IMPORTANT: These economizers meet all the econo-
mizer requirements as specified in ASHRAE 90.1, IECC
and California’s Title 24. Economizer must be installed
square to avoid damper leakage or damper binding.
Squareness tolerance is ±
1
/
32
inch.
IMPORTANT: Read these instructions completely before
attempting to install the accessory economizer.
Table 1 — Carrier Usage Chart
CARRIER MODEL NUMBER ECONOMI$ER
®
X PART NUMBER
Small Cabinet
48/50FC*04-07
48/50GC*04-06
50HCQ 04-06
50KCQ 04-06
50TCQ 04-07
48/50HC, LC 04-06
48/50KC 04-06
48/50TC 04-07
CRECOMZR067A01
Large Cabinet
48/50HC 07-12
48/50LC 07
48/50TC 08-14
50HCQ 07-09
50TCQ 08-12
CRECOMZR069A01
Extra Large Cabinet
48/50HC 14
48/50LC 08-12
48/50TC 16
50HCQ 12
50TCQ 14
CRECOMZR071A01
Table 2 — Bryant Usage Chart
BRYANT MODEL NUMBER ECONOMI$ER
®
X PART NUMBER
Small Cabinet
548J/580J/558J 04-07
549J/547J/559J/582J 04-06
581J/551J 04-06
581K/551K 04-06
582K/559K 04-07
CRECOMZR067A01
Large Cabinet
548J 08-12
549J 07-09
580J/558J 08-14
581J/551J 07-12
CRECOMZR069A01
Extra Large Cabinet
548J 14
549J 12
580J/558J 16
581J/551J 14
CRECOMZR071A01
Table 3 — ICP Usage Chart
ICP MODEL NUMBER ECONOMI$ER
®
X PART NUMBER
Small Cabinet
RGH/RAH 036-060
RGS/RAS 036-072
RGV/RAV 036-072
RGW/RAW 036-060
RGX/RAX 036-060
RHX/RHH 036-060
RHS 036-072
CRECOMZR067A01
Large Cabinet
RAS/RGS 090-150
RGH/RAH 072-120
RHH 072-102
RHS 090-120
CRECOMZR069A01
Extra Large Cabinet
RAS/RGS 150
RGH/RAH 150
RHS 150
RHH 120
CRECOMZR071A01
Table 4 — Package Contents
ECONOMIZER PART
NUMBER
QTY CONTENTS
CRECOMZR067A01,
CRECOMZR069A01
1
EconoMi$er Damper Assembly with
Actuator and HH79AH001 (HW:
C7250) Outside Air Sensor
1
Jade HW63AW002 (HW: W7220)
Controller with Attached Harness*
1
HH79AH001 (HW: C7250) Mixed Air
Temp Sensor*
1
50HE403859 2-(green) wire harness
for mixed air temperature sensor*
1 48TMHSRSE--A20 4-Wire Harness*
1 Hood Assembly with Top and 2 Sides
1 Hood Divider
1 Aluminum Filter
1 Hardware Bag*
CRECOMZR071A01
1
EconoMi$er Damper Assembly with
Actuator and HH79AH001 (HW:
C7250) Outside Air Sensor
1
Jade HW63AW002 (HW: W7220)
Controller with Attached Harness*
1
HH79AH001 (HW: C7250) Mixed Air
Temp Sensor*
1
50HE403859 2-(green) wire harness
for mixed air temperature sensor*
1 48TMHSRSE--A20 4-Wire Harness*
1 Hood Assembly with Top and 2 Sides
1 Hood Divider
1 Hood Filter Divider
2 Aluminum Filters
1 Hardware Bag*
