Table 20 — Parameter Settings — Basic
PARAMETER DESCRIPTION RANGE DEFAULT
2 TEMP OFF
Temperature shutoff setpoint can be obtained automatically if a smartphone
or tablet is connected to the network provided by a Wi-Fi/WLAN stick
plugged into the economizer controller and the Climatix
™
mobile application
is installed on the phone or tablet. This can also be a manually defined
setpoint.
48...80°F, increment by 1 63°F
2ENTH OFF
Enthalpy shutoff setpoint can be obtained automatically if a smartphone or
tablet is connected to the network provided by a Wi-Fi/WLAN stick plugged
into the economizer controller and the Climatix
™
mobile application is
installed on the phone or tablet. This can also be a manually defined
setpoint.
Dynamic item: Appears only if an OAH sensor is configured.
22...30 Btu/lbm, increment by
1
28 Btu/lbm
2DVC
Demand controlled ventilation setpoint can be obtained automatically if a
smartphone or tablet is connected to the network provided by a Wi-Fi/WLAN
stick plugged into the economizer controller and the Climatix
™
mobile
application is installed on the phone or tablet. This can also be a manually
defined setpoint.
Dynamic item: Appears only if a CO
2
sensor is configured.
300...2000PPM, increment by
100
1100PPM
2FAN L ACT
Damper minimum position when fan runs at a low speed.
Dynamic item: Appears only if “6FAN” is configured as “2SPEED” under I/O
Configuration Table.
2...10V 3.6V
2FAN H ACT
Damper minimum position when fan runs at a high speed.
Dynamic item: Appears only if '6FAN' is configured as “1SPEED” or
“2SPEED”.
2...10V, increment by 0.1 2.8V
2VENTMAX L
DCV maximum position when fan runs at a low speed.
Dynamic item: Appears only if a CO
2
sensor is configured and '6FAN' is
configured as “2SPEED”.
2...10V, increment by 0.1 3.6V
2VENTMAX H
DCV maximum position when fan runs at a high speed.
Dynamic item: Appears only if a CO
2
sensor is configured and '6FAN' is
configured as “1SPEED” or “2SPEED”.
2...10V, increment by 0.1 2.8V
2VENTMIN L
DCV minimum position when fan runs at a low speed.
Dynamic item: Appears only if a CO
2
sensor is configured and '6FAN' is
configured as “2SPEED”.
2...10V, increment by 0.1 3.1V
2VENTMIN H
DCV minimum position when fan runs at a high speed.
Dynamic item: Appears only if a CO
2
sensor is configured and '6FAN' is
configured as “2SPEED”.
2...10V, increment by 0.1 2.3V
CFM COMM
Air Flow Chart: CFM commissioning can only be initiated from the
Climatix
™
mobile application. When CFM commissioning is in progress,
the local device reads “CFM COMM”.
— —
2DEGREES Temperature unit (°F or °C) . — °F
2FAN Fan cfm.
100...50,000cfm, increment by
100
5000 cfm
2EX1 L
Exhaust Fan 1 low-speed parameter setting.
Dynamic item: Appears only if:
• Exhaust Fan 1 is configured.
•“6FAN” is configured as “2SPEED”.
0...100%, increment by 1 65%
2EX1 M
Exhaust Fan 1 medium-speed parameter setting.
Dynamic item: Appears only if:
• Exhaust Fan 1 is configured.
0...100%, increment by 1 60%
2EX1 H
Exhaust Fan 1 high-speed parameter setting.
Dynamic item: Appears only if:
• Exhaust Fan 1 is configured.
•“6FAN” is configured as “2SPEED”.
0...100%, increment by 1 50%
2EX2 L
Exhaust Fan 2 low-speed parameter setting.
Dynamic item: Appears only if:
• Exhaust Fan 2 is configured.
•“6FAN” is configured as “2SPEED”.
0...100% 80%
2EX2 M
Exhaust Fan 2 medium-speed parameter setting.
Dynamic item: Appears only if:
• Exhaust Fan 2 is configured.
0...100%, increment by 1 78%
2EX2 H
Exhaust Fan 2 high-speed parameter setting.
Dynamic item: Appears only if:
• Exhaust Fan 2 is configured.
•“6FAN” is configured as “2SPEED”.
0...100%, increment by 1 75%
2THL
Temperature high limitation.
Dynamic item: Appears only if an RAT sensor is configured.
0...100%, increment by 1 83%
2EHL
Enthalpy high limitation.
Dynamic item: Appears only if an RAH sensor is configured.
22...30 Btu/lbm, increment by
1
33 Btu/lbm
2FAN DLY Cooling delay via increasing fan speed. 0...30 min, increment by 1 5 min.
To Next Page
