Carrier Ecologic 30GX080-265 - Page 76

APPENDIX A (cont)
Compressor Must Trip Amps (Determined by CPM Modules) (cont)
COMPRESSOR MUST TRIP AMPS
3-COMPRESSOR UNITS
Unit Size Unit Voltage
Compressor A1, A2, B1
Must Trip Amps
30GX205
230-3-50 418,238,520
380/415-3-50 254,144,314
30GX206
575-3-60 198, 92,162
380-3-60 300,140,246
208/230-3-60 546,254,448
460-3-60 248,114,204
30GX225
230-3-50 520,288,520
380/415-3-50 314,174,314
30GX226
575-3-60 198,110,198
380-3-60 300,168,300
208/230-3-60 546,306,546
460-3-60 248,138,248
230-3-50 520,288,520
380/415-3-50 314,174,314
30GX250
230-3-50 520,418,520
380/415-3-50 314,254,314
30GX251
575-3-60 198,198,162
380-3-60 300,300,246
208/230-3-60 546,546,448
460-3-60 248,248,204
30GX265
575-3-60 198,198,198
380-3-60 300,300,300
208/230-3-60 546,546,546
460-3-60 248,248,248
230-3-50 520,520,520
380/415-3-50 314,314,314
30HXA206
575-3-60 162, 92,198
380-3-60 246,138,300
346-3-50 278,158,344
208/230-3-60 448,254,546
460-3-60 204,116,248
230-3-50 418,238,520
380/415-3-50 254,144,314
30HXA246
575-3-60 198,134,198
380-3-60 300,202,300
346-3-50 344,228,344
208/230-3-60 546,368,546
460-3-60 248,168,248
230-3-50 520,344,520
380/415-3-50 314,208,314
COMPRESSOR MUST TRIP AMPS
3-COMPRESSOR UNITS
Unit Size Unit Voltage
Compressor A1, A2, B1
Must Trip Amps
30HXA261
575-3-60 198,162,198
380-3-60 300,246,300
346-3-50 344,278,344
208/230-3-60 546,448,546
460-3-60 248,204,248
230-3-50 520,418,520
380/415-3-50 314,254,314
30HXA271
575-3-60 198,198,198
380-3-60 300,300,300
346-3-50 344,344,344
208/230-3-60 546,546,546
460-3-60 248,248,248
230-3-50 520,520,520
380/415-3-50 314,314,314
30HXC206
575-3-60 108, 62,130
380-3-60 164, 92,196
346-3-50 182,104,220
208/230-3-60 298,168,358
460-3-60 136, 76,162
230-3-50 274,156,332
380/415-3-50 166, 94,202
30HXC246
575-3-60 130, 90,130
380-3-60 196,136,196
346-3-50 220,152,220
208/230-3-60 358,246,358
460-3-60 162,112,162
230-3-50 332,228,332
380/415-3-50 202,138,202
30HXC261
575-3-60 130,108,130
380-3-60 196,164,196
346-3-50 220,182,220
208/230-3-60 358,298,358
460-3-60 162,136,162
230-3-50 332,274,332
380/415-3-50 202,166,202
30HXC271
575-3-60 130,130,130
380-3-60 196,196,196
346-3-50 220,220,220
208/230-3-60 358,358,358
460-3-60 162,162,162
230-3-50 332,332,332
380/415-3-50 202,202,202
76
