APPENDIX D (cont)
Compressor Protection Module Configuration Header Punch-Outs and Overload Settings (cont)
2-Compressor Units
UNIT
MODEL NUMBER
PUNCH OUTS
FOR CPM-A
PUNCH OUTS
FOR CPM-B
COMP A1
OVERLOAD SETTING
COMP B1
OVERLOAD SETTING
30HXC096---1 1,2,3,5,6,7,8 1,2,3,4,5,6 71 50
30HXC096---2 1,2,4,5,7 1,2,3,5,6,7 108 73
30HXC096---3 1,2,4,7 1,2,3,5 122 83
30HXC096---5 1,3,6,7,8 1,2,5,7,8 197 133
30HXC096---6 1,2,3,6 1,2,3,4,6,8 89 60
30HXC096---8 1,3,5,6,7 1,2,4 183 125
30HXC096---9 1,2,4,5 1,2,3,5,6 111 76
30HXC106---1 1,2,3,6,7 1,2,3,4,5,6 86 50
30HXC106---2 1,2,5,6,8 1,2,3,5,6,7 130 73
30HXC106---3 1,2,6 1,2,3,5 146 83
30HXC106---5 1,5,6,7,8 1,2,5,7,8 238 133
30HXC106---6 1,2,4,5,7 1,2,3,4,6,8 108 60
30HXC106---8 1,4,5,8 1,2,4 220 125
30HXC106---9 1,2,5,7,8 1,2,3,5,6 133 76
30HXC116---1 1,2,3,6,7 1,2,3,4,6,7 86 58
30HXC116---2 1,2,5,6,8 1,2,3,6,8 130 88
30HXC116---3 1,2,6 1,2,4,5,6,7 146 101
30HXC116---5 1,5,6,7,8 1,3,4,5,7,8 238 161
30HXC116---6 1,2,4,5,7 1,2,3,5,6,7 108 73
30HXC116---8 1,4,5,8 1,2 220 152
30HXC116---9 1,2,5,7,8 1,2,3,7,8 133 92
30HXC126---1 1,2,3,6,7 1,2,3,5,6,7,8 86 71
30HXC126---2 1,2,5,6,8 1,2,4,5,7 130 108
30HXC126---3 1,2,6 1,2,4,7 146 122
30HXC126---5 1,5,6,7,8 1,3,6,7,8 238 197
30HXC126---6 1,2,4,5,7 1,2,3,6 108 89
30HXC126---8 1,4,5,8 1,3,5,6,7 220 183
30HXC126---9 1,2,5,7,8 1,2,4,5 133 111
30HXC136---1 1,2,4,5,6 1,2,3,5,6,7,8 103 71
30HXC136---2 1,3,4,5,6,7 1,2,4,5,7 156 108
30HXC136---3 1,3,4,7 1,2,4,7 177 122
30HXC136---5 2,3,4,6 1,3,6,7,8 285 197
30HXC136---6 1,2,5,6,7 1,2,3,6 129 89
30HXC136---8 2,3,4,5,6,7 1,3,5,6,7 267 183
30HXC136---9 1,3,4,5,7,8 1,2,4,5 162 111
30HXC146---1 1,2,4,5,6 1,2,3,6,7 103 86
30HXC146---2 1,3,4,5,6,7 1,2,5,6,8 156 130
30HXC146---3 1,3,4,7 1,2,6 177 146
30HXC146---5 2,3,4,6 1,5,6,7,8 285 238
30HXC146---6 1,2,5,6,7 1,2,4,5,7 129 108
30HXC146---8 2,3,4,5,6,7 1,4,5,8 267 220
30HXC146---9 1,3,4,5,7,8 1,2,5,7,8 162 133
30HXC161---1 1,2,4,6,7,8 1,2,3,5,7,8 112 78
30HXC161---2 1,3,4,6,7 1,2,4,6 170 117
30HXC161---3 1,3,5,7 1,2,5,6 192 132
30HXC161---5 2,3,6,8 1,4,5,6,8 310 214
30HXC161---6 1,2,6,7,8 1,2,3 140 97
30HXC161---8 2,4,5,7 1,3,6,7 289 198
30HXC161---9 1,3,4,7,8 1,2,4,7,8 175 120
30HXC171---1 1,2,3,7 1,2,4,6,7,8 94 112
30HXC171---2 1,2,6,7 1,3,4,6,7 142 170
30HXC171---3 1,3,4,5,6,8 1,3,5,7 158 192
30HXC171---5 1,7,8 2,3,6,8 259 310
30HXC171---6 1,2,4,6 1,2,6,7,8 117 140
30HXC171---8 1,5,6,7,8 2,3,4,7 237 289
30HXC171---9 1,2,6,8 1,3,4,7,8 144 175
30HXC186---1 1,2,4,6,7,8 1,2,4,6,7,8 112 112
30HXC186---2 1,3,4,6,7 1,3,4,6,7 170 170
30HXC186---3 1,3,5,7 1,3,5,7 192 192
30HXC186---5 2,3,6,8 2,3,6,8 310 310
30HXC186---6 1,2,6,7,8 1,2,6,7,8 140 140
30HXC186---8 2,3,4,7 2,3,4,7 289 289
30HXC186---9 1,3,4,7,8 1,3,4,7,8 175 175
