15
HEATER ELECTRICAL DATA
FACTORY--INSTALLED HEATER OPTIONS*
MODEL 019 025 031 037 043 049 061
FX4DNF 5 5 8 10 10 10 10, 15
* For field ---installed heater/fan coil combinations, see Accessory Electric Heaters.
ELECTRIC HEATER INTERNAL PROTECTION
HEATER kW PHASE
FUSE
QTY/SIZE
CKT BKR*
QTY/SIZE
5 1 — 1/60
8 1 — 1/60
9 1/3 — —
10 1 — 1/60
15 1 2/30–2/60 2/60
15 3 — —
18 3 — —
20 1 4/60 2/60
24 1/3 6/60 —
30 1/3 6/60 —
* All circuit breakers are 2 pole.
When using units with 20--, 24--, and 30--kW electric heaters, maintain a 1--in. (25 mm) clearance from combustible materials to discharge
plenum and ductwork and maintain a distance of 36 in. (914mm) from the unit. Use an accessory downflow base to maintain proper clearance
on downflow installations. Use flexible connectors between ductwork and unit to prevent transmission of vibration. When electric heater is
installed, use heat resistant material for flexible connector between ductwork and unit at discharge connection. Ductwork passing through
unconditioned space must be insulated and covered with vapor barrier
ACCESSORIES
ITEM ACCESSORY PART NO.* FAN COIL SIZE USED WITH
1. Disconnect Kit KFADK0201DSC Cooling controls and heaters 3--- through 10--- kW
2. Downflow Base Kit
KFACB0201CFB 019, 025
KFACB0301CFB 031, 037, 043
KFACB0401CFB 049, 061
3. Downflow Conversion Kit
{
KFADC0201SLP Slope Coil Units — 019, 024, 031
KFADC0401ACL A--- Coil Units — 037, 043, 049, 061
4. Downflow/Horizontal Conversion Gasket Kit KFAHD0101SLP All
5. Horizontal Water Management Kit (25 pack)
}
KFAHC0125AAA All
6. Single--- Point Wiring Kit KFASP0101SPK O n l y w i t h 1 5 --- a n d 2 0 --- k W F u s e d H e a t e r s
7. Filter Kit (12 Pack)
KFAFK0112SML NA
KFAFK0212MED 019, 025
KFAFK0312LRG 031 037, 043
KFAFK0412XXL 049, 061
8.
Fan Coil Filter Cabinet
(Fan Coil Filter Media)
FNCCABCC0014
(FILXXFNC0014)
NA
FNCCABCC0017
(FILXXFNC0017)
019, 025
FNCCABCC0021
(FILXXFNC0021)
031, 037, 043
FNCCABCC0024
(FILXXFNC0024)
049, 061
9. PVC Condensate Trap Kit (50 p ack) KFAET0150ETK All
10. Air Cleaner 240--- volt Conversion Kit KEAVC0201240 All
* Factory authorized an d listed, field---installed.
{ KFAHD0101SLP must al so be purcha sed f or downfl ow applications.
} KFAHD0101SLP must also be purchased f or downfl ow or horizontal applications.
FX4D
