INSULATED DUCT CONNECTING
FRESH AIR & EXHAUST TO
OUTSIDE
A
3 Ft.
MIN
FURNACE
REAR
INLET HOOD
6′
EXHAUST HOOD
18″
ERV
A00111
NOTE: Supply & exhaust ducts have
internal balancing dampers
that must be adjusted.
GROUND LEVEL
B
NOTE: A + B = Not less than 10 feet
A05358
Fig. 7 -- Exhaust Ventilation
