Carrier MPPDB-12CRN7-QB6G1 User Manual

Preparation
rear
MODEAL A
MODEAL B
power plug socket
power cord buckle
bottom tray
drain outlet
power cord outlet
drain outlet
(only for pump
heating mode)
upper air filter
(behind the grille)
upper air intake
air outlet
lower air filter
lower air intake
drain outlet
8
front
rear
control panel
handle
(both sides)
horizontal louver
blade
(swing automatically)
Caster
power plug socket
power cord buckle
vent control
bottom tray
drain outlet
power cord outlet
drain outlet
(only for pump
heating mode)
upper air filter
(behind the grille)
upper air intake
air outlet
lower air filter
lower air intake
drain outlet
Panel
SCALE 0.500
GB

Carrier MPPDB-12CRN7-QB6G1 Specifications

General

Brand	Carrier
Model	MPPDB-12CRN7-QB6G1
Category	Air Conditioner
Language	English
