52C,P
SERIES
8
OUTDOOR COIL TUBE
SHEET SCREWS
HUB CLAMP
CONDENSER
FAN
SCREW SCREW
DISCHARGE
GRILLE
FRONT PANEL
(BACK VIEW)
CONTROL DOOR
HINGE PINS
FIGURE 16 — LOCATION OF OUTDOOR
COIL TUBE SHEET SCREWS
FIGURE 17 — REMOVING OUTDOOR COIL
FROM CONDENSER FAN
FIGURE 18 — REMOVING CONDENSER
FAN HUB CLAMP
FIGURE 19 — LOCATION OF SCREWS ON
DISCHARGE GRILLE
