Table 16 — Quick Test, Unit Configuration and Switch Check
LEGEND
*Units are not equipped with oil pressure switches.
QUICK
TEST
STEP NO.
NORMAL
DISPLAY
DESCRIPTION CONTROL SWITCH
1. 01 Type Unit — Air-Cooled VAV Configuration Header
2. 2 No. of Compressors Configuration Header
3.
2
1
No. of Unloaders
(034,038,048-088)
(044, 104)
DIP Switch No. 6 and 7
4. 60 60-Hertz Power Configuration Header
5. 0 or 1
0 — No Reset (Switch Off)
1 — Reset On (Switch On)
DIP Switch No. 2
6. 0 or 1
0 — No Economizer (Switch Off)
1 — Economizer On (Switch On)
DIP Switch No. 3
7. 0 or 1
0 — No Warm-Up (Switch Off)
1 — Warm-Up Used (Switch On)
DIP Switch No. 4
8. 0 or 1
0 — Demand Limit Not Used
(Switch Off)
1 — Demand Limit Used
(Switch On)
DIP Switch No. 5
9. 0 or 1
0 — Enthalpy Switch Open
1 — Enthalpy Switch Closed
EC
1.0. 1 1 — Low-Pressure Switch Closed Low-Pressure Switch 1
1.1. 1 1 — Low-Pressure Switch Closed Low-Pressure Switch 2
1.2. 1 No Circuit 1 Oil Pressure Switch None*
1.3. 1 No Circuit 2 Oil Pressure Switch None*
DIP —
Dual, In-Line Package
EC —
Enthalpy Control
VAV —
Variable Air Volume
