Detailed cooling capacities*
See notes on pg. 31.
EVAP
AIR
CONDENSER ENTERING AIR TEMPERATURES °F
75 85 95 105 115 125
CFM EWB
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
38TZA018-33 Outdoor Section With CK5A/CK5BA024 Indoor Section
525
72 19.79 10.21 1.30 19.80 10.35 1.46 19.29 10.26 1.63 18.30 9.92 1.82 17.10 9.48 2.02 15.88 9.03 2.25
67 19.16 13.22 1.29 18.44 13.04 1.44 17.33 12.60 1.62 16.22 12.14 1.80 15.10 11.69 1.99 13.95 11.23 2.19
63†† 17.89 12.98 1.28 16.79 12.50 1.43 15.82 12.06 1.59 14.77 11.60 1.76 13.73 11.15 1.95 12.57 10.66 2.15
62 17.51 15.79 1.27 16.45 15.32 1.43 15.53 14.88 1.59 14.56 14.41 1.76 13.74 13.74 1.95 12.86 12.86 2.16
57 16.83 16.83 1.27 16.08 16.08 1.42 15.34 15.34 1.58 14.54 14.54 1.76 13.74 13.74 1.95 12.86 12.86 2.16
600
72 19.81 10.35 1.34 19.84 10.60 1.49 19.50 10.65 1.66 18.61 10.40 1.85 17.43 10.00 2.05 16.18 9.55 2.28
67 19.29 13.73 1.32 18.81 13.81 1.47 17.74 13.46 1.64 16.54 12.99 1.84 15.41 12.54 2.03 14.24 12.08 2.23
63†† 18.26 13.69 1.31 17.24 13.32 1.46 16.16 12.85 1.63 15.11 12.41 1.80 14.02 11.94 1.98 12.84 11.45 2.19
62 18.03 16.94 1.30 16.97 16.50 1.46 16.03 16.03 1.62 15.24 15.24 1.80 14.38 14.38 2.00 13.45 13.45 2.21
57 17.74 17.74 1.30 16.87 16.87 1.46 16.05 16.05 1.63 15.24 15.24 1.80 14.37 14.37 2.00 13.45 13.45 2.21
675
72 19.82 10.51 1.36 19.79 10.76 1.52 19.60 10.97 1.69 18.81 10.83 1.88 17.66 10.48 2.08 16.38 10.04 2.30
67 19.30 14.10 1.35 19.01 14.46 1.50 18.03 14.23 1.67 16.84 13.82 1.87 15.67 13.36 2.06 14.45 12.88 2.27
63†† 18.47 14.29 1.34 17.56 14.08 1.49 16.44 13.62 1.66 15.36 13.17 1.83 14.23 12.70 2.02 13.04 12.19 2.23
62 18.40 17.89 1.34 17.56 17.56 1.49 16.67 16.67 1.67 15.80 15.80 1.85 14.90 14.90 2.04 13.97 13.97 2.26
57 18.34 18.34 1.33 17.56 17.56 1.49 16.67 16.67 1.67 15.80 15.80 1.85 14.90 14.90 2.04 13.97 13.97 2.26
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size
Cooling
Indoor
Section Size
Cooling
Capacity Power Capacity Power
CC5A/CD5AA 018 0.98 1.02 CC5A/CD5AW 024 1.00 0.91
024 1.00 1.01 CE3AA 024 1.00 0.91
CC5A/CD5AW 024 1.00 1.01 CK3BA 024 1.00 0.90
CE3AA 024 1.00 1.00 CK5A/CK5BA 018 0.98 0.90
CF5AA 024 1.00 1.00 024 1.00 0.90
CK3BA 024 1.00 1.00 CK5A/CK5BW 024 1.00 0.90
CK5A/CK5BA 018 0.98 1.00 CK5PA 018 0.98 0.92
024 1.00 1.00 024 1.00 0.91
CK5A/CK5BW 024 1.00 1.00 CK5PW 024 1.00 0.91
CK5PA 018 0.98 1.00
COILS + 58CV(A,X)090-16 VARIABLE SPEED FURNACE
024 1.00 1.00
CC5A/CD5AW 024 1.00 0.91
CK5PW 024 1.00 1.00
CE3AA 024 1.00 0.91
F(A,B)4(A,B)N(F,C) 018 0.98 1.00
CK3BA 024 1.00 0.90
024 1.00 0.99
CK5A/CK5BA 018 0.98 0.90
FC4(B,C)NF 024 1.01 1.00
024 1.00 0.91
FE4ANF 002 1.03 0.91
CK5A/CK5BW 024 1.00 0.91
FF1DNA 018 0.98 0.97
CK5PA 018 0.98 0.92
024 1.00 1.00
024 1.00 0.91
FG3AAA 024 1.00 1.02
CK5PW 024 1.00 0.91
FK4(C,D)NF 001 1.01 0.89
COILS + 58MVP060-14 VARIABLE SPEED FURNACE
002 1.03 0.91 CC5A/CD5AW 024 1.00 0.92
FV4(A,B)NF 002 1.03 0.91 CE3AA 024 1.00 0.92
FX4(A,B)NF 018 1.01 1.00 CK5A/CK5BW 024 1.00 0.91
COILS + 58CV(A,X)070-12 VARIABLE SPEED FURNACE CK5PW 024 1.00 0.91
CC5A/CD5AA 018 0.98 0.92 — — —
024 1.00 0.91
