Carrier Performance 12 - Physical Data

3
Physical data
* For tubing sets greater than 50 ft horizontal and/or 20 ft vertical differential, consult Application Guideline and Service Manual—Air Conditioners
and Heat Pumps Using Puron® Refrigerant.
NOTE: See unit Installation Instructions for proper installation.
ACCURATER
®
PISTON CHART
* Piston listed is for any approved non-capillary tube coil combination. Piston is
shipped with outdoor unit and must be installed in approved indoor coil.
CHARGING SUBCOOLING (TXV-TYPE EXPANSION DEVICE * )
* Must be a Puron® refrigerant (R-410A) approved hard shutoff TXV.
UNIT SIZE-SERIES
018-33
024-34 030-33 036-34
042-33
048-33 060-33
Operating Weight (Lb) 168 220 218 221 224 226 284
COMPRESSOR
Type
Scroll
REFRIGERANT Puron® (R-410A)
Control AccuRater® (with Ring)
Charge (Lb) 5.22 5.20 5.19 5.43 5.43 5.75 8.00
COND FAN Propeller Type, Direct Drive
Air Discharge Ver tical
Air Qty (CFM) 1700 2000 2400 2400 2800 2800 3300
Motor HP 1/12 1/10 1/8 1/8 1/5 1/5 1/4
Motor RPM 1100 1100 825 825 825 825 1100
COND COIL Copper Tube, Aluminum Plate Fin
Face Area (Sq ft) 10.9 10.9 12.2 12.2 12.2 12.2 18.2
Fins per In. 25 25 25 25 25 25 25
Rows 1111111
Circuits 2222223
VALVE CONNECT. (In. ID) Sweat
Vapor 5/8 5/8 3/4 3/4 7/8 7/8 7/8
Liquid 3/8
REFRIGERANT TUBES* (In. OD)
Vapor (0–50 Ft Tube Length)
5/8 5/8 3/4 3/4 7/8 7/8 1-1/8
Vapor (Max Diameter for Long-
Line Applications)
3/4 3/4 7/8 7/8 1-1/8 1-1/8 1-1/8
Liquid (0–50 Ft Tube Length) 3/8
Liquid (For Long-Line
Applications)
3/8
UNIT SIZE-SERIES
PISTON*
IDENTIFICATION NO.
018-33 49
024-34 55
030-33 63
036-34 67
042-33 76
048-33 80
060-33 90
UNIT SIZE-SERIES REQUIRED SUBCOOLING (°F)
018-33 10
024-34 10
030-33 11
036-34 11
042-33 9
048-33 10
060-33 11
