Carrier Performance 12 - Page 27

27
Detailed cooling capacities* continued
See notes on pg. 31.
EVAP
AIR
CONDENSER ENTERING AIR TEMPERATURES °F
75 85 95 105 115 125
CFM EWB
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
38TZA042-33 Outdoor Section With CK5A/CK5B048 Indoor Section
1225
72 46.2 22.9 3.13 44.9 22.5 3.49 42.8 21.8 3.88 40.4 21.0 4.31 37.9 20.2 4.78 35.1 19.3 5.33
67 43.8 30.2 3.10 41.7 29.4 3.44 39.5 28.5 3.82 37.1 27.6 4.24 33.5 26.1 4.68 29.4 24.6 5.17
63†† 38.4 28.3 3.03 35.6 27.1 3.34 32.7 25.9 3.70 31.0 25.2 4.11 29.2 24.4 4.58 25.6 23.0 5.06
62 37.9 35.5 3.02 35.2 34.2 3.34 32.7 32.7 3.69 31.3 31.3 4.12 29.8 29.8 4.59 27.7 27.7 5.12
57 37.1 37.1 3.00 34.9 34.9 3.33 32.7 32.7 3.70 31.7 31.7 4.13 30.4 30.4 4.61 27.7 27.7 5.12
1400
72 46.8 23.7 3.21 45.0 23.2 3.56 43.0 22.5 3.95 40.7 21.8 4.38 38.3 21.2 4.87 35.4 20.3 5.41
67 44.3 31.8 3.18 42.1 30.8 3.51 40.0 30.2 3.90 37.6 29.4 4.33 33.9 27.9 4.77 29.8 26.4 5.26
63†† 39.6 30.3 3.11 36.7 29.1 3.43 34.0 27.9 3.79 32.3 27.2 4.21 30.4 26.5 4.68 26.8 24.9 5.16
62 39.0 38.1 3.10 36.7 36.7 3.43 35.4 35.4 3.81 34.0 34.0 4.25 32.1 32.1 4.72 28.9 28.9 5.22
57 38.6 38.6 3.10 37.4 37.4 3.44 35.2 35.2 3.81 34.1 34.1 4.25 31.9 31.9 4.72 29.1 29.1 5.23
1575
72 47.3 24.5 3.29 45.6 24.1 3.64 43.5 23.5 4.03 41.1 22.8 4.46 38.6 22.2 4.96 35.7 21.3 5.50
67 44.7 33.2 3.25 42.2 32.1 3.58 40.2 31.7 3.97 38.0 31.0 4.40 34.6 29.8 4.85 30.4 28.2 5.35
63†† 41.8 32.7 3.21 37.9 31.1 3.52 35.1 29.9 3.88 33.4 29.2 4.30 31.1 28.2 4.77 27.0 26.4 5.24
62 41.3 41.1 3.20 39.3 39.3 3.54 37.8 37.8 3.93 36.3 36.3 4.36 33.2 33.2 4.82 29.9 29.9 5.33
57 41.1 41.1 3.20 39.6 39.6 3.55 37.4 37.4 3.92 36.2 36.2 4.36 33.1 33.1 4.82 30.3 30.3 5.34
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size
Cooling
Indoor
Section Size
Cooling
Capacity Power Capacity Power
CC5A/CD5AC 048 0.99 1.00 CE3AA 042 0.98 0.92
CC5A/CD5AW 042 0.99 1.00 048 0.99 0.92
048 1.00 1.00 CK3BA 042 0.98 0.92
CD5AA 048 1.00 1.00 048 0.99 0.92
CE3AA 042 0.99 0.99 CK5A/CK5BA 042 0.98 0.92
048 1.00 1.00 048 0.99 0.92
CF5AA 048 0.99 0.99 CK5A/CK5BE 042 0.99 0.93
CK3BA 042 0.99 0.99 CK5A/CK5BT 042 0.98 0.92
048 1.00 1.00 048 0.99 0.92
CK5A/CK5BA 042 0.99 0.99 CK5PA 042 0.98 0.92
048 1.00 1.00 048 0.99 0.92
CK5A/CK5BT 042 0.99 0.99 CK5PE 042 0.99 0.93
048 1.00 1.00 CK5PT 042 0.98 0.92
CK5A/CK5BW 048 1.00 1.00 048 0.99 0.92
CK5PA 042 0.99 0.99
COILS + 58CV(A,X)110-20 VARIABLE SPEED FURNACE
048 1.00 1.00
CC5A/CD5AA 042 0.98 0.93
CK5PT 042 0.99 0.99
CC5A/CD5AC 048 0.98 0.93
048 1.00 1.00
CC5A/CD5AW 042 0.96 0.92
CK5PW 048 1.00 1.00
048 0.99 0.93
F(A,B)4(A,B)N(F,B,C) 042 0.99 1.01
CD5AA 048 0.99 0.93
048 1.00 1.00
CE3AA 042 0.98 0.92
FC4(B,C)N(F,B) 042 0.96 1.00
048 0.99 0.93
048 0.99 1.01
CK3BA 042 0.98 0.93
FC4(B,C)NB 054 1.01 0.97
048 0.99 0.92
FE4ANB 006 1.01 0.89
CK5A/CK5BA 042 0.98 0.93
FE4ANF 003 0.96 0.91
048 0.99 0.93
005 1.01 0.92
CK5A/CK5BE 042 0.98 0.92
FG3AAA 048 1.00 1.00
CK5A/CK5BT 042 0.98 0.93
FK4(C,D)NB 006 1.01 0.89
048 0.99 0.93
FK4(C,D)NF 003 0.96 0.91
CK5A/CK5BW 048 0.99 0.92
005 1.00 0.91
CK5PA 042 0.98 0.93
FV4(A,B)NB 006 1.01 0.89
048 0.99 0.92
FV4(A,B)NF 003 0.96 0.91
CK5PE 042 0.98 0.92
005 1.01 0.92
CK5PT 042 0.98 0.93
FX4(A,B)NF 042 0.96 0.98
048 0.99 0.92
048 0.99 0.99
CK5PW 048 0.99 0.92
COILS + 58CV(A,X)090-16 VARIABLE SPEED FURNACE COILS + 58CV(A,X)135-22 VARIABLE SPEED FURNACE
CC5A/CD5AA 042 0.98 0.92 CC5A/CD5AA 042 0.98 0.91
CC5A/CD5AC 048 0.98 0.92 CC5A/CD5AC 048 0.98 0.91
CD5AA 048 0.99 0.92 CC5A/CD5AW 042 0.98 0.92
—— — 048 0.99 0.91
CD5AA 048 0.99 0.91
