SPECIFICATIONS
Heating Capacity and Efficiency 040-10 060-14 080-16 100-16 120-22
Input High Heat (BTUH) 40,000 60,000 80,000 100,000 120,000
Output High Heat (BTUH) 39,000 58,000 78,000 98,000 117,000
Efficiency AFUE % (ICS) 96.5 96.5 96.5 96.5 96.5
Certified Temperature
Rise Range ºF (ºC)
High Heat
40 - 70
(21-38)
40 - 70
(21-38)
40 - 70
(21-38)
40 - 70
(21-38)
40 - 70
(21-38)
Airflow Capacity and Blower Data 040-10 060-14 080-16 100-16 120-22
Certified External Static
Pressure (in. w.c.)
Heating 0.10 0.12 0.15 0.20 0.20
Cooling 0.5 0.5 0.5 0.5 0.5
Airflow Delivery
@RatedESP(CFM)
High Heat 695 1000 1360 1730 2125
Cooling 925 1505 1610 1720 2055
Cooling Capacity (tons)
@ 400, 350 CFM/ton
400 CFM/ton 2 3.5 4 4 5
350 CFM/ton 2.5 4 4.5 5 6
Direct-Drive Motor Type Electronically Commutated Motor (ECM)
Direct-Drive Motor HP 1/2 3/4 3/4 1 1
Motor Full Load Amps 6.8 8.4 8.4 10.9 10.9
RPM Range 600 - 1200
Speed Selections 5
Blower Wheel Dia x Width in. 11x7 11x8 11x8 11x10 11 x 11
Air Filtration System
Factory Supplied Media Cabinet
FieldSuppliedFilter
Filter Used for Certified Watt Data
KGAWF1606UFR KGAWF1306UFR KGAWF1406UFR KGAWF1506UFR KGAWF1506UFR
Electrical Data 040-10 060-14 080-16 100-16 120-22
Input Voltage Volts-Hertz-Phase 115-60-1
Operating Voltage Range Min-Max 104-127
Maximum Input Amps Amps 8.1 9.7 9.7 12.2 12.2
Unit Ampacity Amps 11.0 13.0 13.0 16.1 16.1
Minimum Wire Size AWG 14 14 14 12 12
Maximum Wire Length
@ Minimum Wire Size
Feet 33 28 28 35 35
(M) (10.1) (8.5) (8.5) (10.7) (10.7)
Maximum Fuse/Ckt Bkr
(Time-Delay Type Recommended)
Amps 15 15 15 20 20
Transformer Capacity (24vac output) 40 VA
External C ontrol Power
Available
Heating 24.3 VA
Cooling 34.6 VA
Controls 040-10 060-14 080-16 100-16 120-22
Gas Connection Size 1/2” - NPT
Burners (Monoport) 2 3 4 5 6
Gas Valve (Redundant)
Manufacturer White Rogers™
Minimum Inlet Gas
pressure (in. W.C.)
4.5
Maximum Inlet Gas
pressure (in. W.C.)
13.6
Gas Conversion Kit - Natural to Propane KGANP50011SP
Gas Conversion Kit - Propan e to Natural KGAPN42011SP
Manufactured (Mobile) Home Kit KGAMH0301KIT
Ignition Device Silicon Nitride
Limit Control 165 180 170 160 160
Heating Blower Control (Heating Off-Delay) Adjustable: 90, 120, 150, 180 seconds
Cooling Blower Control (Time D el ay Relay) 90 seconds
Communication System none
Thermostat C onnections Y1, DHUM, G C W, Y/Y2, R
Accessory Connections EAC (115vac); HUM (24vac); 1-stg AC (via Y/Y2)
