SPECIFICATIONS
Heating Capacity and Efficiency 040-10 060-14 080-16 080-20 100-20 120-22
Input
High
Heat
(BTUH) 40,000 60,000 80,000 80,000 100,000 120,000
Low
Heat
(BTUH) 26,000 39,000 52,000 52,000 65,000 78,000
Output
High
Heat
(BTUH) 39,000 58,000 78,000 78,000 97,000 117,000
Low
Heat
(BTUH) 25,000 38,000 50,000 51,000 63,000 76,000
Efficiency AFUE % (ICS) 96.5 96.3 96.2 96.7 96.1 96.7
Certified Temperature
Rise Range ºF (ºC)
High Heat
40 - 70
(22 - 39)
40 - 70
(22 - 39)
40 - 70
(22 - 39)
40 - 70
(22 - 39)
40 - 70
(22 - 39)
40 - 70
(22 - 39)
Low Heat
30 - 60
(17 - 33)
30 - 60
(17 - 33)
30 - 60
(17 - 33)
30 - 60
(17 - 33)
30 - 60
(17 - 33)
30 - 60
(17 - 33)
Airflow Capacity and Blower Data 040-10 060-14 080-16 080-20 100-20 120-22
Certified External Static
Pressure (in. w.c.)
Heating 0.10 0.12 0.15 0.15 0.20 0.20
Cooling 0.5 0.5 0.5 0.5 0.5 0.5
Airflow Delivery
@ Rated ESP (CFM)
High Heat 695 1000 1360 1360 1700 2125
Low Heat 590 785 1095 1055 1325 1610
Cooling 925 1505 1610 2015 2110 2055
Cooling Capacity (tons)
@ 400, 350 CFM/ton
400 CFM/ton 2 3.5 4 5 5 5
350 CFM/ton
2.5 4 4.5 5.5 6 6
Direct-Drive Motor Type Electronically Commutated Motor (ECM)
Direct-Drive Motor HP 1/2 3/4 3/4 1 1 1
Motor Full Load Amps 6.8 8.4 8.4 10.9 10.9 10.9
RPM Range 600 - 1200
Speed Selections 5
Blower Wheel Dia x Width in. 11 x 7 11 x 8 11 x 8 11 x 10 11 x 10 11 x 11
Air Filtration System
Factory Supplied Media Cabinet
Field Supplied Filter
Filter Used for Certified Watt Data
KGAWF1606UFR KGAWF1306UFR KGAWF1306UFR KGAWF1406UFR KGAWF1406UFR KGAWF1506UFR
Electrical Data 040-10 060-14 080-16 080-20 100-20 120-22
Input Voltage Volts-Hertz-
Phase
115-60-1
Operating Voltage Range Min-Max 104-127
Maximum Input Amps Amps 7.5 9.2 9.2 11.7 11.8 11.8
Unit Ampacity Amps 10.3 12.4 12.4 15.5 15.6 15.6
Minimum Wire Size AWG 14 14 14 12 12 12
Maximum Wire Length
@ Minimum Wire Size
Feet 36 29 29 37 36 36
(M) (11.0) (8.8) (8.8) (11.3) (11.0) (11.0)
Maximum Fuse/Ckt Bkr
(Time-Delay Type Recom-
mended)
Amps 15 15 15 20 20 20
Transformer Capacity (24vac output) 40 VA
External Control Power
Available
Heating 24.3 VA
Cooling 34.6 VA
Controls 040-10 060-14 080-16 080-20 100-20 120-22
Gas Connection Size 1/2" - NPT
Burners (Monoport) 2 3 4 4 5 6
Gas Valve (Redundant)
Manufacturer White Rogers
Minimum Inlet
Gas pressure
(in. wc)
4.5
Maximum Inlet
Gas pressure
(in. wc)
13.6
Gas Conversion Kit - Natural to Propane KGANP51012SP
Gas Conversion Kit - Propane to Natural KGAPN43012SP
Manufactured (Mobile) Home Kit not approved for MH use
Ignition Device Silicon Nitride
Limit Control 165 180 170 200 180 160
Heating Blower Control (Heating Off-Delay) Adjustable: 90, 120, 150, 180 seconds
Cooling Blower Control (Time Delay Relay) 90 seconds
Communication System none
Thermostat Connections Com 24V, R, W/W1, G, Y/Y2, DHUM, Y1, W2
Accessory Connections EAC (115vac); HUM (24vac); 1-stg AC (via Y/Y2)
59TP5A
