Model number nomenclature (cont)
HJQ – High Efficiency Heat Pump
50– Electric Cooling
1 – Revision Number
FIOP Code*
Nominal Capacity
004 – 3 Tons
005 – 4 Tons
006 – 5 Tons
007 – 6 Tons
008 – 7 1/2 Tons
009 – 8 1/2 Tons
012 – 10 Tons
V-Ph-Hz
3 – 208/230-1-60
5 – 208/230-3-60
6 – 460-3-60
50 HJQ 004 P - - 3 1 1 A A
Packaging
1 – Domestic Unit
3 – Export
Controls and Sensors
– – None
G – Hinged Access Panels
H – Hinged Panels & PremierLink
N – Novar ETM3051 Control
P – PremierLink DDC Control
R – Novar ETM3051 & Hinged Panels
Indoor Motor Options
– – Standard Motor and Drive
M – High Static Motor
Coil Options
– – Aluminum Fin/Copper Tube (Indoor and Outdoor Coils)
B – Copper Fin/Copper Tube (Indoor and Outdoor Coils)
C – Copper Fin/Copper Tube (Outdoor Coil) and
Aluminum Fin/Copper Tube (Indoor Coil)
E – E-Coated Aluminum Fin/Copper Tube (Indoor and
Outdoor Coils)
F – E-Coated Aluminum Fin/Copper Tube (Outdoor Coil)
and Aluminum Fin/Copper Tube (Indoor Coil)
G – E-Coated Copper Fin/Copper Tube (Outdoor Coil) and
Aluminum Fin/Copper Tube (Indoor Coil)
V – Pre-Coated Aluminum Fin/Copper Tube (Outdoor Coil)
and Aluninum Fin/Copper Tube (Indoor Coil)
50 HJQ 016 - - C 6 2 1 YA
HJQ – High Efficiency Heat Pump
Fan Drive Motor
- – Standard Motor
50 – Electric Cooling
Design Series
2 – Gear Driven EconoMi$er IV
Design Change
Factory Installed Option Code*
Normal Capacity
014 – 12 1/2 Tons
016 – 15 Tons
Service/Control Options
- – Standard Controls
G – Service Option with 6 Hinged Access Panels,
Non-Fused Disconnect, and Non-Powered
115-v GFI Convenience Outlet
J – Hinged Access Panels
Voltage Designation
1 – 575-3-60
5 – 208/230-3-60
6 – 460-3-60
Coil Protection Options
- – Al/Cu Outdoor & Indoor Coils
B – Cu/Cu Outdoor & Indoor Coils
C – Cu/Cu Outdoor & Al/Cu Indoor Coils
F – E-Coated Al/Cu Outdoor
G – E-Coated Cu/Cu Outdoor
V – Pre-coated Outdoor Coil
Packaging
1 – Domestic
3 – Export
*Refer to 50HJQ Price Pages for FIOP (factory-installed option)
code table.
50HJQ004-012
*Refer to 50HJQ price pages or contact your local Carrier representa-
tive for 50HJQ code table.
50HJQ014,016
Quality Assurance
Certified to ISO 9001:2000
Quality Assurance
Certified to ISO 9001:2000
