7
ARI* CAPACITY RATINGS — 50TFQ004-006
ARI* CAPACITY RATINGS — 50TFQ007-012
LEGEND
*Air Conditioning and Refrigeration Institute.
†Applies only to units with capacity of 60,000 Btuh or less.
**The IPLV applies only to 2-stage cooling heat pump units.
NOTES:
1. Rated in accordance with ARI Standards 210/240-95 and 270-95.
2. Ratings are net values, reflecting the effects of circulating fan heat.
3. ALL the 50HJQ and 50TFQ004,005 and 006 units are in compliance with ASHRAE 90.1
2001 Energy Standard for minimum SEER and EER requirements. Refer to state and local
codes or visit the following website: http://solstice.crest.org/efficiency/bcap to determine if
compliance with this standard pertains to a given geographical area of the United States.
4. Ratings are based on:
Cooling Standard: 80Fdb,67 F wb indoor entering-air temperature and 95 F db air entering
outdoor unit.
IPLV Standard: 80Fdb,67 F wb indoor entering-air temperature and 80 F db outdoor entering-
air temperature.
High-Temp Heating Standard: 70 F db indoor entering-air temperature and 47 Fdb,43Fwb
outdoor entering-air temperature.
Low-Temp Heating Standard: 70 F db indoor entering-air temperature and 17 Fdb,15Fwb
outdoor entering-air temperature.
UNIT
50TFQ
NOMINAL
TONS
COOLING
HEATING
(High Temp)
SOUND
RATING
(decibels)
Net Capacity
(Btuh)
SEER†
Capacity
(Btuh)
HSPF
Belt
Drive
Direct
Drive
004 3 35,600 10.20 10.00 34,400 6.784
005 4 46,500 10.00 9.70 46,500 7.0 80
006 557,000 10.00 9.90 57,000 7.5 82
UNIT
50TFQ
NOMINAL
TONS
COOLING
HEATING
(High)
HEATING
(Low)
IPLV**
SOUND
RATING
(decibels)
Net Capacity
(Btuh)
EER
Capacity
(Btuh)
COP
Capacity
(Btuh)
COP
007 6 70,000 9.05 72,400 3.20 42,000 2.14 — 82
008 7
1
/
2
86,000 9.00 78,000 3.00 39,000 1.809.3 86
009 8
1
/
2
96,000 8.90 96,000 3.00 55,000 2.00 8.85 86
012 10 112,000 9.00 105,000 3.10 59,000 2.00 9.0 84
COP—Coefficient of Performance
db — dry bulb
EER — Energy Efficiency Ratio
HSPF — Heating Seasonal Performance Factor
IPLV — Integrated Part-Load Values
SEER — Seasonal Energy Efficiency Ratio
wb—wet bulb
ARI* capacity ratings
