CARRYBOY SR5 - CFTD-SR5 REV00 2

5
4
C
A
R
R
Y
B
O
Y
INSTALLATION MANUAL
2/7
Install rubber truck edge under the hardtop.
Hardtop
Sponge rubber edge
Tape page 2
3
4
Place hardtop on the truck bed and adjust alignment
between left and right.
Install kwick klamp for 6 positions.
5
4 PERSONS
2
3
SR5
FORD RANGER T6 D/CAB
CFTD-SR5
.
C-132701-01
19/11/61
REV : 00
Remove the nut’s spring washer
5A
5B
Adjust the position to fix loose bolts on the Al. rail.
(Remarks : In case of having bed liner,Al. Klamp
must be fixed at the flat area of the bed liner)
Fixed
Fixed
Fixed
Loose
Loose
Loose
and washer from 3 loose bolts. Then, put the
upper Al. clonp klamp on the Al. rail throngh the hole on the
top
of upper Al. klamp. Tighter nuts, spring washer and washer
back to its original position to lock the upper Al.klamp.
5C
No.13
7 NM
40
HOLE SAW 40
Hole saw cut line
Inner lower
edge line
13 mm.
In the case of having bed liner, the bed liner must
be drilled with a hole saw O 40 mm. at the same
level of truck‘s inner lower edge.
3
5
1
4
6
2
FRONT
Put the lower Al. klamp throngh
the bolt M8x70 follow the diagram.
Then,tighten the lower Al. klamp with
truck’s inner lower edge and bolt M8x70.
2
4
6
1
5
3
