CARRYBOY SR5 - CFTD-SR5 REV00 3

INSTALLATION MANUAL
3/7
6
7
10
6
9
9
8
No.13
7 NM
Installing latch R/L on the rear door.
7
8
Adjust a latch R/L for matching with the slam lock
on the rear door.
Shock apsorber assembly.
Top
11
No.13
7 NM
Bottom
11
Final check the appearance.
9
Stick CARRYBOY resin sticker R/L.
14
10
SILICONE
SR5
FORD RANGER T6 D/CAB
CFTD-SR5
.
13
C-132701-01
19/11/61
REV : 00
CARRYBOY
CARRYBOY
CARRYBOY







12
R/L
