Carter 2503 - Suspension Arm Assembly

SUSPENSION ARM ASSEMBLY
REF NO PART NO DESCRIPTION REQD NO
1 5002514 9.108.095 FLANGE BOLT M8 X 1.25 X 95 2
2 5363014 7.010.003 UPPER SUSPENSION ARM BUSH 8
3 5362509 8.010.104 UPPER SUSPENSION ARM COLLAR 2
4 5362510 4.000.020 UPPER SUSPENSION ARM 2
5 5001043 9.220.008 LOCKING FLANGE NYLON NUT M8 8
6 5001080 9.108.030 FLANGE BOLT M8 X 1.25 X 30 4
7 5532503 6.000.172 CUSHION ASS'Y. FR 2
8 5002515 9.108.100 FLANGE BOLT M8 X 1.25 X 100 2
9 5362511 8.010.015 LOWER SUSPENSION ARM COLLAR 2
10 5362512 4.000.021 LOWER SUSPENSION ARM ASS'Y 2
11 5212503 2.000.031 SPINDLE AND STRUT SUPPORT, R 1
12 5222503 9.030.010 BEARING 6202 2
13 5182503 6.000.169 FRONT WHEEL ASS'Y 2
14 5222504 9.030.009 BEARING 6201 2
15 5003006 9.220.012 LOCKING FLANGE NUT M12 2
16 5203004 7.020.039 HUB COVER FR 2
17 5002516 8.010.141 ACORN NUT M10 2
18 5192503 6.000.182 RIM, FR 2
19 5162503 6.000.169 TIRE, FR 4.1-6 2
20 5212504 2.000.032 SPINDLE AND STRUT SUPPORT, L 1
21 5372504 7.020.061 BALL HEAD DUST SEAL 4
27
