Carter 2503 - Rear End

REAR END
REF NO PART NO DESCRIPTION REQD NO
1 F110 HEX BOLT 5/16" X 3/4" NC 1
2 3001549 CENTER LOCK NUT 7/16" 3
3 F422 FLAT WASHER 5/16" 2
4 3001550 NUT, 7/16" 1
5 3001548 TAP SCREW 10/24 X 1/4" 8
6 3001551 WOODRUFF KEY #6 1
7 3001552 CAP SCREW 7/16" X 1" NF 1
8 F412 LOCK WASHER 7/16" 1
9 F424 WASHER USS 3/8 1
10 3001554 BOLT CARRRIAGE 1/4" X 3/4" NC 1
11 F404 LOCK WASHER 1/4" 1
12 3001069 WHIZ NUT 1/4" NC 1
13 3451459 MFG BUSHING PIVOT 5/8"OD X.328"ID 1
14 3451460 MFG SPACER 1"OD X.455(+/-.005)"ID 2
15 5001306 9.100.616 BOLT M6X16 2
16 5001086 9.400.006 LOCK WASHER M6 2
17 3002012 SCREW, 10X3/8 HEX TYA 10
18 3009009 PUSH RETAINER 5/16" EXT 4
19 3402004 FLAG POLE BRACKET 1
20 3391112 INERTIA DISK 1
21 3391113 MOLDED RUBBER DISK 1
22 3311103 CHAIN #35-38 PITCHS 1
23 3221107 BEARING 1 3/8" X 7/16" 4
24 3402284 BEARING BRACKET BLACK 1
25 3441010 SUB PRIMARY SHAFT 1
26 3441011 SUB REDUCTION SHAFT 1
27 3502500 FRAME PAINTED ENGINE MT 1
28 3452658 BUSHING REAR END MT 1
29 3372660 BELLY GUARD BLACK 1
30 F116 ENGINE MT BOLTS 5/16 x 1 1/4 3
31 F1003 3/8" SAE FLAT WASHER 4
32 5003004 9.108.050 REAR END MT BOLTS M8 X 50 2
33 5001073 9.200.008 NUT M8 2
34 F422 5/16 FLAT WASHER 2
35 F1017 5/16 NUT ,WHIZ 3
36 3130147 ENGINE. 3.5 HP TECUMSEH 1
37 5523017 6.000.178 CALIPER ASSY 1
38 5532504 6.000.173 SHOCK REAR 2
39 3372661 ENGINE GUARD 1
40 5001080 9.108.030 FLANGE BOLT M8 X 1.25-30 4
41 5003039 9.210.008 NYLON LOCK NUT M8 4
31
