Carter CT08 - Page 14

Seal package
Code
Name (reference dimensions mm)
Quantity
1
Dust cover (OD 50.9)
1
2
Copper sheet (OD 60.45)
1
3
Seal ring of output shaft (OD 63.56)
1
4
O-ring (ID92.87 ， Shore hardness70)
1
5
End seal ring (ID 45.72)
1
6
O-ring (ID 6.07)
2
7
O-ring (ID 94.97)
2
8
O-ring (ID 11.2)
1
9
Front-type seal ring (ID 62.23)
1
10
Front-type seal ring (ID 35.82)
1
11
O-ring (ID 92.33 ， Shore hardness 90)
1
14
