Carter CT08 - Appearance Parameters; Working Parameters

Appearance parameters
Overall dimensions
CT08
CT10
Unit: mm
A Wheel track
900
900
B Overall length of track
1233
1233
C Ground clearance of platform
385
385
D Ground clearance of platform tail
800
815
E Chassis width
840
840
F Crawler width
180
180
H Crawler height
324
324
I Transportation length
2876
2976
J Overall height （ Driving shed top ）
1495
1495
Deflection angle left °/ right °
/
50°/70°
Working parameters
Work range
CT08
CT10
Unit: mm
A Max. digging radius on ground
2992
3125
B Max. digging depth
1787
1520
C Max. digging height
2550
2585
D Max. unloading height
1687
1715
E Max. vertical digging depth
1626
/
F Min. swing radius
1483
1595
G Max. lifting height of dozer blade
340
340
H Max. digging depth of dozer blade
260
260
Performance parameters
Weight of complete machine kg
850
920
Standard bucket capacity m³
0.022
0.022
Rated power kw
7.0
7.0
