CARVIN X-AMP User Manual

X-50B/X-100B Specifications
Input Impedance 2.2 Meg ohms
Maximum Input Level before clipping Hi 1:1.5V rms, Lo 2: 3V rms
EQ Tone Controls—Bass ±15 dB shelving below 200 Hz
Mid ±9 dB peak/dip at 500 Hz
Treble ±15 dB peak/dip at 4K Hz
Presence ±15 dB shelving above 8K Hz
Graphic EQ Freq. 75, 150, 500, 1.5k & 3k Hz ±18dB
Hot Rod Gain +20 dB with Master Volume pulled out
Effects Loop -10, 0, or +4 dB adjustable
Line Output +4 dBV 600Ω XLR
Power Output—X50B 50 watts rms (145 watts peak)
X100B 100 watts rms (250 watts peak)
Adjustable Power Output 25%, 50%, and full power
Output Impedance 4, 8, and 16 ohms
Output Tubes—X-50B Two EL34's
X-100B Four EL34's
Pre Amp Tubes Three12AX7’s
Power Requirements 120/240 VAC 50-60 Hz
Fuse 120V: 3.15 Amp. 240V: 2 Amp— slow-blow 5x20mm
Dimensions 29”W x 10”D x 11”H
Shipping Wt X50B—46 lbs, X100B—49 lbs
XT112, XV112 & XV212 Specifications
Input Impedance 2.2 Meg ohms
Maximum Input Level before clipping Hi 1:1.5V rms, Lo 2: 3V rms
EQ Tone Controls—Bass ±15 dB shelving below 200 Hz
Mid ±9 dB peak/dip at 500 Hz
Treble ±15 dB peak/dip at 4K Hz
Presence ±15 dB shelving above 8K Hz
Graphic EQ Freq. 75, 150, 500, 1.5k & 3k Hz ±18dB
Hot Rod Gain +20 dB with Master Volume pulled out
Effects Loop -10, 0, or +4 dB adjustable
Line Output +4 dBV 600Ω XLR
Power Output—XT112 50 watts rms (145 watts peak)
XV112, XV212 100 watts rms (250 watts peak)
Speaker(s) XT112/XV112: one Carvin BR12 XV212: two BR12's
Adjustable Power Output 25%, 50%, and full power
Output Impedance 4, 8, and 16 ohms
Output Tubes— XT112 Two EL34's
XV112 Four EL34's
Pre Amp Tubes Three12AX7’s
Power Requirements 120/240 VAC 50-60 Hz
Fuse 120V: 3.15 Amp. 240V: 2 Amp— slow-blow 5x20mm
Dimensions—XT112, XV112 22”W x 10.5”D x 21”H
Shipping Wt XT112—59lbs, XV112—61lbs
Dimensions—XV212 26”W x 10.5”D x 21”H
Shipping Wt XV212—71lbs
X60 Specifications
Input Impedance 2.2 Meg ohms
Maximum Input Level before clipping Hi 1:1.5V rms, Lo 2: 3V rms
EQ Tone Controls—Bass ±15 dB shelving below 200 Hz
Mid ±9 dB peak/dip at 500 Hz
Treble ±15 dB peak/dip at 4K Hz
Presence ±15 dB shelving above 8K Hz
Hot Rod Gain +20 dB with Master Volume pulled out
Effects Loop 0 dBV
Power Output 60 watts rms (155 watts peak)
Speaker One Carvin BR12
Output Impedance 4, 8, and 16 ohms
Output Tubes Output: Two EL34's Pre Amp: Three 12AX7's
Power Requirements 120/240 VAC 50-60 Hz
Fuse—120VAC 120V: 3.15 Amp. 240V: 2 Amp—slow-blow 5x20mm
Dimensions 18”W x 10.5”D x 18”H. Shiping Wt 45 lbs
