CHAPTER 2
8 Case IH 3230/3240/3320/3330/3340 & 4420/4430/4440, Model Year 2010 & Newer ISO AutoBoom® Installation Manual
Valve - AutoBoom Hydraulic 063-0131-124 1
Node - Case IH ISO AutoBoom 063-0130-053 1
Sensor - Left Ultrasonic 063-0130-012 1
Sensor - Right Ultrasonic 063-0130-014 1
Sensor - Center Ultrasonic 063-0130-018 1
Bracket - Valve Mounting 107-0171-802 1
Bracket - Sensor Mounting 107-0172-501 3
Cable - 60’ Ultrasonic Sensor Extension 115-0230-051 2
Cable - AutoBoom Harness 115-0230-073 1
U-Bolt - 2-1/16” W x 3” L x 3/8” Thread 107-0171-609 4
U-Bolt - 3-9/16” W x 4” L x 3/8” Thread 107-0172-471 2
TABLE 1. UltraGlide Installation Kit (P/N 117-0232-130)
Picture Item Description Part Number Qty.
