Case IH 4440 - Autoboom Installation Kit - 120 Booms

2
P/N 016-0230-129 Rev. A 9
INTRODUCTION
AUTOBOOM INSTALLATION KIT - 120’ BOOMS
U-Bolt - 2-9/16” W x 3-1/2” L x 3/8”
Thread
107-0171-616 4
Bolt - 5/816”-18 x 7/8” Hex 311-0052-104 4
Bolt - 3/8”-16 UNC x 1-1/4” Hex 311-0054-081 15
Nut - 3/8”-16 Zinc Flanged Lock 312-1001-164 31
Washer - 5/816” Zinc Lock 313-1000-019 4
TABLE 2. UltraGlide Installation Kit (P/N 117-0232-129)
Picture Item Description Part Number Qty.
Not Pictured
Manual - ISO AutoBoom for Case IH
Calibration and Operation
016-0130-079 1
Not Pictured
Manual - Case IH 3230/3240 and 3320/
3330/3340/4420/4430/4440, Model Year
2010 & Newer AutoBoom Installation
016-0230-129 1
Valve - AutoBoom Hydraulic 063-0131-124 1
Node - Case IH ISO AutoBoom 063-0130-053 1
TABLE 1. UltraGlide Installation Kit (P/N 117-0232-130)
Picture Item Description Part Number Qty.
