Case IH AXIAL-FLOW 7230 - General Specifications Summary

INTRODUCTION
Generalspecication
72308230
Feeder
NumberofChains
4
Chaintype
557HD
NumberofSlats
Unitswithoutrocktrap42
Unitsequippedwithrocktrap36
SlattypeRollFormedSerratedU-Slat
Driveline,xedGearboxandShaft
Driveline,variable
GearboxandShaft-CVT
FeederClutch
Friction
HeaderLiftcylinders,diameter.75mm(3in)
Highcapacity90mm(3.5in)
ReverserSystem
Hydraulic
StoneTrap(Opt.)Beater/Sump
Threshing
ThreshingDrive
DriveType
GearboxandShaft-CVT
RotorSpeedRange
220–1180RPM
SpeedControl
Electronic
Rotor
RotorDiameter
762mm(30in)
RotorLength
2623mm(103.3in)
Lengthofaugersection515mm(20.3in)
Lengthofthreshingsection886mm(34.9in)
Lengthofseparationsection886mm(34.9in)
Lengthofdischargesection305mm(12in)
Rotor
Corn
NumberofNonSpikedRaspBars
56
NumberofSpikedRaspBars
8
HighAlloyNo
NumberStraightSeparatorBars
4
NumberHelicalSeparatorBars
2
SmallGrain
NumberofNonSpikedRaspBars
64
NumberofSpikedRaspBars
8
HighAlloyNo
NumberStraightSeparatorBars
4
NumberHelicalSeparatorBars
2
ST
NumberofNonSpikedRaspBars
40
Spiked,HighAlloy
Yes
NumberHelicalSeparatorBars
2
RotorModules
Numberofseparatingsections
4
Numberofthreshingsections
4
ClearanceRange120mm(4.7in)
WrapAngle
180°
SeparationConceptCentrifugalforce
4804083715/08/2017
26
