Engine-Engineandcrankcase
3.1.Installtheenginetotransmissionleft-handsidere-
tainingbolts.
2.Torqueto285-315Nm(210-232lbft).
BAIL15TR00016AA2
4.1.Installtheenginetotransmissionright-handside
retainingbolts.
2.Torqueto285-315Nm(210-232lbft).
BAIL13TR00797AB3
5.A.Installtheenginetotransmissionupperretaining
bolts.
B.Torqueto285-315Nm(210-232lbft).
NOTE:Thecenterboltisuniqueinlength.
BAIL13TR00798AB4
6.A.Installtheenginetotransmissionlowerouterre-
tainingbolts.
B.Torqueto285-315Nm(210-232lbft).
BAIL14TR00969AB5
4793872419/10/2015
10.1[10.001]/52
