HYDRAULIC,PNEUMATIC,ELECTRICAL,ELECTRONICSYSTEMS-PRIMARYHYDRAULICPOWERSYSTEM
BAIL07APH352ASA25
SteeringCylinders.
Receiveshighpressureoildirectlyfromthesteeringmotor.
BSE2868B26
LoadSensingShuttleValve.
Locatedineachremotevalveslice,theElectronicDraftControlvalveandbetweenthetrailerbrakevalve,frontsus-
pensionvalveandmid-mountedvalves,wheretted,istheloadsensingshuttlevalve(2)Figure27.Thisallowsthe
functionwiththehighestpressuredemandtosendsensingpressuretotheloadsensingvalve,Figure28,onthe
variabledisplacementpump.
BSB0388A_43627
84479138A06/06/2011
A.10.A/27
