INTRODUCTION
Component
Torque
CounterShaftBearingRetainerPlateMountingBolts125–150N·m(92–111lbft)
SpindleHousing310–380N·m(229–280lbft)
RingGearRetainingPlate310–380N·m(229–280lbft)
SunGearShaftRetainingPlate125–150N·m(92–111lbft)
OutputGearBearingRetainerPlateMountingBolts125–150N·m(92–111lbft)
PlanetaryCarriertoDriveHub310–380N·m(229–280lbft)
FinalDrivetoFrameMountingBolts
656–725N·m(484–535lbft)
FillCheckPlug24–30N·m(18–22lbft)
DrainPlug
24–30N·m(18–22lbft)
CabMounting
Component
Torque
Supportmountbolts733–854N·m(541–630lbft)
Brushguardmountbolts(ifequipped)587–794N·m(433–586lbft)
AirConditioningCompressor
Component
Torque
Compressorrotorshaftnut15–20Nm(11–15lbft)
Oilllerplug15–24Nm(11–18lbft)
Dustcoverscrews
7–11Nm(5–8lbft)
LiftCylinder
Component
Torque
Pistonbolt
2160–2450N·m(1593–1807lbft)
Gland135–542Nm(100–400lbft)
TiltCylinder
Component
Torque
Pistonbolt
2160–2450N·m(1593–1807lbft)
Gland135–542Nm(100–400lbft)
AngleCylinder
Component
Torque
Pistonbolt
2160–2450N·m(1593–1807lbft)
Gland135–542Nm(100–400lbft)
RipperCylinder
Component
Torque
Pistonbolt
2830–3210N·m(2087–2368lbft)
Gland135–542Nm(100–400lbft)
Starter
Component
Torque
Mountingbolts
68–77Nm(50–57lbft)
Batteryterminalnut
17.7–24.5Nm(13–18lbft)
Solenoid+screw2.6–4.5Nm(23–40lbin)
Multifunctionvalve
Component
Torque
Brakevalve
3–4N·m(2–3lbft)
Brakevalvescrews
3–4N·m(2–3lbft)
Cartridgevalve32.6–35.4N·m(24.0–26.1lbft)
Checkvalve150–177N·m(111–131lbft)
4804856726/04/2017
38
