Case 1650M - Torque - Special Torques

INTRODUCTION
Torque-Specialtorques
1650MWE
Ripper
Component
Torque
Rippermountingbolts
1016–1375N·m(749–1014lbft)
Ripperpinretainingandtubecoverbolts
301–407N·m(222–300lbft)
FuseandRelayBlocks
Component
Torque
Fuseblockmounting
2.7Nm(24lbin)
Bussedstuds
8.5Nm(75lbin)
PowerRelays
Component
Torque
Outputstuds5.4Nm(48lbin)
Inputstuds
16.3Nm(144lbin)
EngineMounts
Component
Torque
Enginemountboltstochassis
205–230Nm(151–170lbft)
Rearenginemountbracketstobellhousing
118–133Nm(87–98lbft)
Frontenginemountbrackettoengineblock
118–133Nm(87–98lbft)
Startermountingbolts68–77Nm(50–57lbft)
EnginetoPumpsDriveShaft
Component
Torque
Flywheelmountbolts
285–305Nm(210–225lbft)
PumpsandMotors
Component
Torque
Pumpmountboltstoframe68–81Nm(50–60lbft)
Motormountboltstonaldrives250–280N·m(184–207lbft)
Pumptomotorhosesspitangeclamps90–100Nm(66–74lbft)
Inlethoseclamps
6.5–7.6Nm(58–68lbin)
RearFrameCover
Component
Torque
M24hexbolts
449–725N·m(331–535lbft)
M16hexbolts
230–371N·m(170–274lbft)
Track
Component
Torque
Masterlinkbolts(UseLOCTITE®242®onmasterlink
bolts.)
610.0–670.0N·m(449.9–494.2lbft)
Standardlinkshoebolts610.0–670.0N·m(449.9–494.2lbft)
FinalDrives
Component
Torque
DriveHubRollingT orque
8–15N·m(71–133lbin)
InputShaftBearingRetainerPlateMountingBolts77–87N·m(57–64lbft)
ParkBrakeHousingPlate
77–87N·m(57–64lbft)
BrakeHousingCover-M20X5012pnt650–730N·m(479–538lbft)
BrakeLineFitting
55–60N·m(41–44lbft)
BrakeBleederFitting
24–30N·m(18–22lbft)
4804856726/04/2017
37
