Engine-Engineandcrankcase
Engineandcrankcase-Torque
Mainenginecomponents
Item
Threaddiameterxpitch
Tighteningtorque
MainM10X1.25
75.3-83.4N·m(55.54-61.51lbft)
Cylinderheadbolt
Sub
M8X1.25
19.6-29.4N·m(14.46-21.68lbft)
RockercovernutM6X1.0
4.9-6.9N·m(3.61-5.09lbft)
Rockerstaybolt
M8X1.25
14.7-21.6N·m(10.84-15.93lbft)
Mainbearingcapbolt
M10X1.25
49.0-53.9N·m(36.14-39.75lbft)
Connectingrodcapnut
M8X1.0
31.4-34.3N·m(23.16-25.3lbft)
Flywheelbolt
M10X1.25
83.4-93.2N·m(61.51-68.74lbft)
Crankshaftpulleynut
M16X1.5
98.1-117.7N·m(72.35-86.81lbft)
84533370B20/05/2014
10.1[10.001]/3
