Engine-Engineandcrankcase
EngineModel
L3E
Lubricationsystem
Pressurefeed,fullowlter
system
Specication
ClassCDoraboveoil(API
serviceclassication)
Engineoil
(Enginetotal)capacity3.6l(0.95USgal)
Type
Geartype(internaland
externalteethengagement),
builtintothegearcase
Oilpump
Flow
3l(0.79USgal)l/1min
(1min)ormore(at1000RPM)
Type
Pistonvalve
Reliefvalve
Valveopeningpressure
0.261-0.319MPa(37.86-
46.27psi)(1000RPM)
Lubricationsystem
Oillter
Type
Paperlterelement
CoolingsystemForced-feedcirculationtype
Coolantcapacity(mainenginecomponents)1.8l(0.48USgal)
Type
Centrifugalvolutetype
Waterpump
Dischargerate
50l(13.21USgal)/1min(at
pumprotationof4500RPM)
Type
Waxpellet
Thermostat
Valveopeningpressure
75-78°C(167-172°F)
TypePushtype
Coolingsystem
Coolingfan
Numberofblades/outer
diameter
5equallyspacedblades/
310mm(12.2in)
Inletsystem
Aircleaner
Type
Paperlterelement
Voltage-polarity
12V-negative(-)ground
Type
M001T68381
ManufacturerMitsubishiElectricCorporation
Pinionengagementtype
Withreduction
Output12V-1.7kW(2.31Hp)
Number1
Startermotor
Pinion/ringgearratio
14/106
Typenumber
A007TA0171B
Type
Three-phasecurrent
generator,integralwithIC
regulator
Manufacturer
MitsubishiElectricCorporation
Output
12V-40A
Ratedvoltagegenerating
speed
5000RPM(at13.5V,37A,
whenhot)
Alternator
Regulatoradjustingvoltage
14.4-15V(14-15V)
Type
Sheathed
Glowplug
Ratedvoltage-current
11V-8.5-10.5A(8.5-
10.5A)(6sduration)
Workingvoltage
12V
Insulationresistance
100Ω(100Ω)orhigher
measuredwith500Vcc
(normaltemperature,normal
relativehumidity)
Stroke
13-14mm(0.51-0.55in)
Electric
Stopsolenoid
Ambienttemperatureforuse
-40-120°C(-40-248.00°F)
84533370B20/05/2014
10.1[10.001]/5
