Case 2050M Tier 4A interim - Special Torque Applications

INTRODUCTION
Torque-Specialtorques
2050MNA
Ripper
Component
Torque
Rippermountingbolts
1016-1375N·m(749-1014lbft)
Ripperpinretainingandtubecoverbolts
301-407N·m(222-300lbft)
FuseandRelayBlocks
Component
Torque
Fuseblockmounting
6.5N·m(4.8lbft)
PumpsandMotors
Component
Torque
Pumpmountboltstocover
587-690N·m(433-509lbft)
Motormountboltstonaldrives250-280N·m(184-207lbft)
Pumptomotorhosesspitangeclamps90-100Nm(66-74lbft)
Inlethoseclamps
6.5-7.6Nm(58-68lbin)
RearFrameCover
Component
Torque
M24hexbolts
449-725N·m(331-535lbft)
M16hexbolts
230-371N·m(170-274lbft)
Track
Component
Torque
Masterlinkbolts(UseLOCTITE®242®onmasterlink
bolts.)
610-670N·m(450-494lbft)
Standardlinkshoebolts610-670N·m(450-494lbft)
FinalDrives
Component
Torque
DriveHubRollingTorque
10-24N·m(7-18lbft)
InputShaftBearingRetainerPlateMountingBolts77-87N·m(57-64lbft)
ParkBrakeHousingPlate
77-87N·m(57-64lbft)
BrakeHousingCover-M20X5012pnt650-730N·m(479-538lbft)
BrakeLineFitting
55-60N·m(41-44lbft)
BrakeBleederFitting
24-30N·m(18-22lbft)
CounterShaftBearingRetainerPlateMountingBolts135-150N·m(100-111lbft)
SpindleHousing335-375N·m(247-277lbft)
RingGearRetainingPlate335-375N·m(247-277lbft)
SunGearShaftRetainingPlate135-150N·m(100-111lbft)
OutputGearBearingRetainerPlateMountingBolts135-150N·m(100-111lbft)
PlanetaryCarriertoDriveHub335-375N·m(247-277lbft)
FinalDriveHousingtoFrameMountingBolts
656-725N·m(484-535lbft)
FillCheckPlug24-30N·m(18-22lbft)
DrainPlug
24-30N·m(18-22lbft)
CabMounting
Component
Torque
Supportmountbolts733-854N·m(541-630lbft)
Brushguardmountbolts(ifequipped)587-794N·m(433-586lbft)
4790787120/10/2015
21
