INTRODUCTION
CAUTION
Heavyobject!
Thecomponentisheavy.Usecarenottodrop
thecomponentwheninstalling,removing,or
handling.
Failuretocomplycouldresultinminoror
moderateinjury.
C0095A
10.Accessthelowerpressurereliefvalvebyremoving
thecenterbellypancover(3)underneaththema-
chine.Thelowerpressurereliefvalve(4)islocated
onthefronthydrostaticpump.
RAIL13DOZ0274AA12
RAIL13DOZ1710AA13
11.Removethereliefvalveplasticcaps((5)toaccess
theengagementscrews(6).Theplasticcapswillbe
unusableafterremovalandshouldbereplaced.
RAIL12DOZ0644AA14
12.UseanAllenwrench,andturntheengagementscrew
(6)counterclockwisetwoturnsoneachreliefvalve.
RCIL10CWL116AAL15
