INTRODUCTION
Returningtheunittoservice
1.Disconnectthehandpumpfromthebrakelines.
2.Removetheplugs,andreconnectthelines(1)tothe
brakesolenoid.
RAPH12DOZ0094AA18
3.Removethevacuumpumpandinstallthehydraulic
reservoirbreather.
RAIL12DOZ0372AA19
4.Turntheengagementscrewsclockwisetwoturnson
eachreliefvalve.
RCIL10CWL116AAL20
4790787120/10/2015
33
