INTRODUCTION
Gasketsealants
Prod-
uct
ColorStrengthFixture/Full
Cure(Steel/
Steel)Time
Recom-
mended
Primeror
Activator
Description
592White0.113-
0.330Nm(1
-3lbin)
72hrs
none
Isamediumstrengthanaerobicsealantwith
Teon®fortaperedpipethreads.Thehigh
lubricatingpropertiesofthiscompoundprevent
gallingonpipethreadsandttings.Itwillprovide
immediatelowpressuresealingandallowthe
readjustmentofttingsshortlyafterassembly.After
72hoursthejointissealedtopipeburstpressure.
598Metallic
black
1.31MPa
(190psi)
25min/72hrs
none
Thisproductresistsaging,weatheringandthermal
cyclingwithouthardening,shrinkingorcracking.
Typicalapplicationsincludeoilpans,transmission
pans,valvecovers,valvesandguides,timing
gearcovers,anddifferentialcovers.Thisproduct
istypicallyusedinapplicationswithanoperating
rangeof-54-260°C(-65-500°F).
Threadlockerandsealing
Prod-
uct
ColorStrengthFixture/Full
Cure(Steel/
Steel)Time
Recom-
mended
Primeror
Activator
Description
204Pink12.4-24.9Nm
(110-220lbin)
10min/72hrs
none
Isadry-to-the-touch,preappliedlmforthreaded
fasteners.Itremainsinertonthefasteneruntil
assemblyofthethreadsreleasesaquickcuring
resin.Theresinllsallthevoidsinthethreadsand
curestosecurelylockandsealtheassembly.
222Purple
4-14Nm(35-
124lbin)
20min/3hrs
7471or
7469
Isdesignedforthelockingandsealingofthreaded
fastenerswhichrequireeasydisassemblywith
standardhandtools.
242Blue
5.6-17Nm(50
-150lbin)
3min/6hrs
7471or
7469
Isdesignedforthelockingandsealingofthreaded
fastenerswhichrequirenormaldisassemblywith
standardhandtools.
243Blue
7-24Nm(62-
212lbin)
10min/1hr
7471or
7469
Isdesignedforthelockingandsealingofthreaded
fastenerswhichrequirenormaldisassemblywith
standardhandtools.
246Blue
2-5.7Nm(18-
50lbin)
10min/6hrs
7471or
7469
Isdesignedforthelockingandsealingofthreaded
fastenerswhichrequirenormaldisassemblywith
standardhandtools.Theproductcureswhen
connedintheabsenceofairbetweenclose
ttingmetalsurfacesandpreventslooseningand
leakagefromshockandvibration.Particularly
suitableforheavydutyapplicationssuchasbolts
usedintransmissions,constructionequipmentor
railroadassemblieswhereresistancetoheavy
shock,vibrationandstresslevelisrequiredalong
withexposuretoelevatedtemperatures.
262Red
22-40Nm(195
-354lbin)
15min/7hrs
7471or
7469
Isdesignedforthepermanentlockingandsealing
ofthreadedfasteners.
271Red16.9-34Nm
(150-300lb
in)
10min/24hrs
7471or
7469
Isdesignedforthepermanentlockingandsealing
ofthreadedfasteners.
277Red
32-40Nm(283
-354lbin)
30min/7hrs
7471or
7469
Isdesignedforthepermanentlockingandsealing
ofthreadedfasteners.
