Case 521F - Page 45

2000-12
84581916A Issued 3-12 Printed in E.C.
STEP 39
BD07N596-01
BD07N583-01
BD07N584-01
Remove the radiator hose (1) from the rear of the
engine, remove the heater hose from the rear of the
engine (2), remove the clamp bolts and clamps (3)
from the bell housing.
STEP 40
BD07N585-01
Tag and remove the grid heater cable.
STEP 41
BD07N586-01
Disconnect the wiring harness from the EDC 7
controller.
NOTE: Lifting up on the lever will release the
connector from the controller.
STEP 42
BD07N591-01
Remove the fuel line from the top of the EDC 7
controller, plug the line and cap the fitting.
1
2
3
