Case 521G - Page 45

Engine-Engineandcrankcase
32.Afterremovingthebeltcover,removethecover
mountingbracketfromtherightrearsideofmachine
frame.
LEIL16WHL1343AB30
33.Ifmachineisequippedwiththeairconditioningsys-
tem,identify,tag,anddisconnecttheenginewiring
harnessconnectorsfromtheaircompressorclutch
connector(1).
Recoverytherefrigerant,asindicatedinAircondi-
tioning-Serviceinstruction(50.200).Disconnect
thelow-pressureline(2)fromthesuctionportand
thehigh-pressureline(3)fromthedischargeport,lo-
catedonthecompressor.Immediatelyinstallprotec-
tivecapsontheopenportsandlines.
LEIL16WHL1349AB31
34.Removethebelt(4).Removethethreemounting
bolts(2).Removethebolt(3)andcarefullyremove
thecompressor(1)withthesupportbracket.
LEIL16WHL1380AB32
35.Removethedrivebeltfromtheengine.
LEIL15WHL0192AB33
48082189_EN14/02/2017
10.1[10.001]/12
